Specifications
Rotating Bituminous Membrane Oven1.Temperature of workroom: 163 degrees Celsius
2.Size of workroom: 450mm*450mm*510mm
Rotating Bituminous Membrane Oven Model SLH-0609
I. Summary
The SLH-0609 Asphalt Thin Film Oven(82 type oven for short) is design and made as per T0609-1993 Thin Film Oven Test in the industry standard of People’s Republic of China JTJ052-2000 Specification and Test Method of Bitumen and Bituminous Mixture for Highway Engineering. It is suitable to test the quality loss after heating the road asphalt film. And also test the change of needle penetration, softening point, breaking point and ductility for asphalt residue as need to evaluate the aging resistance property of asphalt.
II. Main technical specifications and parameters
1.Power supply: AC220V±10%,50Hz
2.Power: 2.5KW
3.Temperature of workroom: 163±0.5 degrees Celsius
4.Temperature control accuracy: ±0.5 degrees Celsius
5.Rotate speed of turn plate: (5.5r±1r)/min
6.Test sample quantity: 4 pieces
7.Size of workroom: 450mm×450mm×510mm
8.Ambient temperature: 5°C~50°C
9.Relative humidity: ≤85%
Features: stainless steel material for liner, inner door, and container
Rotating Bituminous Membrane Oven/ Rotation Film Oven for Asphalt /Asphalt Thin Film Oven / Asphalt Tester / Bitumen Instrument / Asphalt Test Apparatus
