Bitumen Ductility Test Apparatus / Ductility Testing Machine / Asphalt Ductility Tester

Specifications

Bitumen Ductility Tester
-Max. ductility extent: 1.5 m
-ASTM D113
-For testing ductility and stress force of bitumen

Bitumen Ductility Test Apparatus Model: SLH -4508F

I.Summary
The instrument is designed and made according to the regulations of standards of GB/T4508,ASTMD113,T0605 bitumen ductility test, to determinate bitumen length in regulated temperature and speed stressed and be broken, and at the same time to determinate stress force for one of samples

II.Main Technical Features
1.The humanized design concept, test all screw groove guide rail and other devices, sample installation is very convenient, maximum tensile length is 1.5meters.
2.It adopts the microcomputer control technology, test results by the micro printer to print automatically,Equipped with a RS-232 standard interface, it can communicate with a computer conveniently.
3.With a load device, one of them in both do extensive test sample, and synchronous tensile test.
4.After the stretching, test can be automatically return to the accurate positioning.

III. Main technical specifications and parameters
1. Power supply: AC 220 V (-5%~+10%), 50 Hz;
2. Measurement range: 1.5 m (±10mm);
3. Heating power: 3200 W;
4. Temperature controlling range: 5~50°C; digitally displayed;
5. Temperature controlling accuracy: ±0.1°C;
6. Dragging speed: two grades, 10 mm/min and 50 mm/min;
7. Measurement accuracy: ±1 mm;
8. Dragging force measurement range: 0~100kg;
9. Dragging force accuracy: ±0.5kg
10.Data output:(1)Communicate with a computer through a RS232 port; (2)Printed out by a micro-printer
11. Refrigeration type: by a compressor; input power is 950 W
12. Ambient temperature: -10~+35°C;
13. Relative humidity: ≤85%.
14. Total power consumption: not more than 4500 W.
15.Boundary dimension :2365mm*530mm*1000mm(L*W*H)
