EFPE-120 New EPE Foam Sheet Extrusion Machine Line(CE APPROVED )
EPE foam machine can make different foam sheet width and thickness according to customer requirement. Meanwhile, it can also make foam pipe, foam net, foam rod, foam profile and so on through changing mould and machine parts.
The foam sheet has the features of dampproof , shockproof, soundproof, heat preservation and good plasticity. After laminating, the foam sheet will get high dampproof performance. These products are mainly used for placing under floor.
Applications:
I. Characteristics of Product
--High resilience and buoyant effect.
--Effective insulating capability.
--Low thermal conductivity.
--Negligent absorption and water permeability.
--Chemical resistant.
--Effective and safe to handle in installation application.
--Non-toxic and environmental friendly
--Fine round closed-cell cellular structure assure
--Excellent flexibility.
--100% recyclable and reusable.
II. Applications of Product
--External cushioning and packing material.
--Packaging for high-grade goods, industrial electronic parts.
--Construction materials for insulation
--Educational material
--Sport material
--Life vest etc.
Main Technical Parameters
Model |
Unit |
EPE90 |
EPE105 |
EPE120 |
EPE150 |
EPE170 |
Screw diameter L/D |
|
90/55:1 |
105/55:1 |
120/55:1 |
150/55:1 |
170/55:1 |
Screw speed |
r/min |
5-45 |
5-45 |
5-45 |
5-45 |
5-45 |
Foam rate |
|
20-40 |
20-40 |
20-40 |
20-40 |
20-40 |
Width of product |
mm |
1000-1400 |
1000-1500 |
1000-2000 |
1000-2000 |
1000-2000 |
Thickness of product |
mm |
0.5-4.5 |
0.5-6.5 |
0.8-8 |
1-12 |
2-16 |
Cooling method |
|
cooled by water |
||||
Installed capacity |
kw |
90 |
100 |
120 |
150 |
180 |
Dimensions(L×W×H)(approx) |
m |
22×2.3×2.2 |
23×2.3×2.2 |
25×2.3×2.2 |
30×2.3×2.2 |
32×2.3×2.2 |
Total weight(approx) |
t |
8.5 |
9 |
12 |
15 |
17 |
