Characteristics:
Q35Y series combines punching and shearing machine, featuring multi-functions, including cutting, punching, shearing, notching and bending.
We can design the machine according to your demands.
Efficient productivity with low energy-consumption, diversified goods with flexible operation, and over-long life with simple maintenance make our machine the prefect device for metal processing.
Workspace:
1 punching workspace
1 ) Different punching dies meet different manufacturing needs.
2 ) Punch fixture system can greatly save time but have great accuracy.
3 ) Stripping plate is specially-designed, and easily-operated.
4 ) Stripping baffle matches all sizes of punching.
5 ) Two job boards with scale and positioning block make it operate easily.
2 flat shear workspace
1 ) Special curve design on blades avoids most of the distortion.
2 ) The lower shear blades can be replaced from flank.
3 ) Positioning plate with support table make it easier to adjust the work.
4 ) Cutting edges can be done on the angle of iron-butt.
3 round Square steel shear workspace
1 ) Used for round, square steel shearing.
4 angle iron shear workspace
1 ) No material loss by using the single blade shearing.
2 ) Produce beautiful and practical 45°/90° notching easily.
3 ) Lower blade has four usable edges.
5 shear angle workspace
1 ) Dock flat, angle iron conveniently.
2 ) The cover, together with the electrical interlock, guarantees the safety.
Technical Data:
Model |
Q35Y-16 |
Pressure (Ton) |
65 |
Maximum cutting thickness (mm) |
16 |
One stroke shears size (D*W)(mm) |
16*250 8*400 |
Slide stroke(mm) |
80 |
Stroke frequency (beats/min) |
12 |
Throat depth (mm) |
300 |
Punching thickness (mm) |
16 |
Maximum Punching diameter(mm) |
25 |
Main motor power (kw) |
4 |
Dimensions (L*W*H)(mm) |
1640*730*1770 |
Main configuration:
Main electrical appliance |
1 Set |
SCHNEIDER |
Hydraulic part |
1 Set |
TAIWAN HNC |
Sealing element |
1 Set |
JAPAN NOK |
Main motor |
1 Set |
SIEMENS |
Hydraulic pump |
1 Set |
TAIWAN HYDROMAX(GEAR PUMP) |
Note: T Steel, Industrial steel, Channel steel need special order.
Usage:
1. Steel Processing |
2. Car and auto parts processing |
3. Trailer spare parts, trailer hinges, Walloon board |
4. Construction machinery industry --- belt conveyor and mixing station processing |
5. Agricultural machinery industry --- thresher frame body, trailer body and parts processing |
6. Food Industry Machinery --- slaughtering equipment, rack body and parts processing |
7. High voltage tower --- body and parts processing |
8. Wind power generation equipment --- stairs and pedal parts processing |
9. Building machining --- building embedded parts, conveyor brackets and other parts processing |
10. Food machinery --- starch, grain and oil equipment; cover equipment and small parts processing |
11. Transportation machinery --- railway, wagons / vehicles and crane parts processing |
Anhui LIFU Machinery Technology CO., LTD is a comprehensive company specializing in producing forging equipments, drawing and punching mould;
The main products are power press, ironworker, hydraulic press machine, related moulds, specialized in drawing and punching mould;
Mainly applicated in kitchen, household, aviation, light industry, metallurgy, chemical engineering, building, shipping, automobile, electric application, etc;
More than sixty after-service network spreads all over our country to provide best service, which gain great appraise both at home and abroad;
After the establishment of the ahlifu, based on the management of the product quality, we devote ourselves to orchestrate the quality with high-quality, fresh design, reasonable price, and European standard;
In future, We will keep refining on the appearance, structure, theory, configuration, setting, and performance of the products in our company.
