Characteristics:
Type Y41-63T Single Column Arber Hydraulic Press is a kind of medium-small hydraulic press with multi functions suitable for the calibration of the parts like bearings and moulding materials and for the arber of parts like bearings and sleeves. At the time, the machine can also complete the technology function of bending, making, and shelling of plate material parts, and the function of stretching of simple parts, and the function of stretching of simple parts. It can also be used to press powder and plastic products which the requirements are not strict.
Type Y41 series products are suitable for the flow assembly of machine tool, internal combustion, textile machinery, axle bearing, washing machine, automobile motor, air conditioner motor, electric appliance in military enterprise and joint venture enterprise.
Our factory has a strong technique force and can meet any requirement from customer such as technical parameter, specification and tonnage.
Main Technical Parameters:
No. |
Type |
Units |
Y41-63T |
Remark |
|
1 |
Nominal force |
KN |
630 |
|
|
2 |
The pressure of the working system |
MPa |
25 |
|
|
3 |
The maximum daylight opening |
mm |
700 |
|
|
4 |
Throat depth |
mm |
300 |
|
|
5 |
The stroke of the slipper |
mm |
400 |
|
|
6 |
Velocity of the slipper |
Idle |
mm/s |
60 |
|
Return |
mm/s |
60 |
|
||
Working |
mm/s |
8-12 |
|
||
7 |
The size of the Working platform |
Left, Right |
mm |
600 |
|
Front, Rear |
mm |
700 |
|
||
8 |
Dimension(L*W*H) |
mm |
1250*800*2450 |
|
|
9 |
The power for motors |
KW |
5.5 |
|
|
Anhui LIFU Machinery Technology CO., LTD is a comprehensive company specializing in producing forging equipments, drawing and punching mould;
The main products are power press, ironworker, hydraulic press machine, related moulds, specialized in drawing and punching mould;
Mainly applicated in kitchen, household, aviation, light industry, metallurgy, chemical engineering, building, shipping, automobile, electric application, etc;
More than sixty after-service network spreads all over our country to provide best service, which gain great appraise both at home and abroad;
After the establishment of the ahlifu, based on the management of the product quality, we devote ourselves to orchestrate the quality with high-quality, fresh design, reasonable price, and European standard;
In future, We will keep refining on the appearance, structure, theory, configuration, setting, and performance of the products in our company.
