SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver

SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver thumbnail-1
SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver thumbnail-2
SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver thumbnail-3
SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver thumbnail-4
SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver thumbnail-5
SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver thumbnail-6
SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver photo-1
SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver photo-2
SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver photo-3
SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver photo-4
SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver photo-5
SH Link Telecom Products Hot Pluggable Duplex sc 10G CWDM X2 Transceiver photo-6
US$ 1 - 100 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SH
Model Number:
SHX2-10G-Cxx-40
Contact Supplier Request Quote Chat Now
Shenzhen SH Link Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SH
Model Number SHX2-10G-Cxx-40

SH Link telecom products Hot pluggable duplex sc 10G CWDM X2 transceiver

Product Description



SHX2-10G-Cxx-40 CWDM X2 optical transceiver consists of a 10.3Gbit/s optical transmitter and receiver, XAUI interface, Mux and Demux with clock and data recovery(CDR), widely used in typical router line card applications, Storage, IP network and LAN. It complies with X2 Multi-Source Agreement (MSA) Specification. The high-performance cooled EML transmitter and high-sensitivity PIN receiver provide superior performance up to link length of 40km on single mode fiber.



Features
  • XAUI Electrical Interface: 4 Lanes 3.125Gbit/s
  • Hot Z-Pluggable
  • Duplex SC connector
  • Support MDIO, DOM
  • Compliant to IEEE 802.3ae 10GBASE-ER Application
  • Compliant to X2 MSA
  • Adaptable Power Supply (APS: +1.2 V)
  • Power dissipation: <4W
  • Temperature range 0°C to 70°C
  • RoHS Compliant Part
Application
  • 10GBASE-ER/EW Ethernet
  • CWDM Networks
  • Compatible with many switches, such as:

SH Link telecom products Hot pluggable duplex sc 10G CWDM X2 transceiver

Ordering Information



Part Number

Data Rate

Distance

Wavelength

Laser

Fiber

DDM

Connector

SHX2-10G-C47-40

10Gb/s

40km

1470nm

EML/PIN

SM

Yes

Duplex SC

SHX2-10G-C49-40

10Gb/s

40km

1490nm

EML/PIN

SM

Yes

Duplex SC

SHX2-10G-C51-40

10Gb/s

40km

1510nm

EML/PIN

SM

Yes

Duplex SC

SHX2-10G-C53-40

10Gb/s

40km

1530nm

EML/PIN

SM

Yes

Duplex SC

SHX2-10G-C55-40

10Gb/s

40km

1550nm

EML/PIN

SM

Yes

Duplex SC

SHX2-10G-C57-40

10Gb/s

40km

1570nm

EML/PIN

SM

Yes

Duplex SC

SHX2-10G-C59-40

10Gb/s

40km

1590nm

EML/PIN

SM

Yes

Duplex SC

SHX2-10G-C61-40

10Gb/s

40km

1610nm

EML/PIN

SM

Yes

Duplex SC



Specifications



Parameter

Symbols

Min.

Typ.

Max.

Unit

Transmitter

Center Wavelength

λC

λ-6.5

λ

λ+6.5

nm

Spectral Width

Δλ





1

nm

Signaling speed



-

10.3125

-

Gbit/s

Optical Output Power

Po

 -1

-

+4

dBm

Extinction Ratio

Er

 8.2

-



dB

Off Transmit Power

Poff

 -

-

-30

dBm

Receiver

Center Wavelength

λC

1260



1620

nm

Receiver Stressed Sensitivity In OMA

Senst





-16

dBm

Receiver Overload

Rro

 -1

-

-

dBm

Signal Detect De-assert Level

PSDD





-17

dBm

Signal Detect Assert Level

PSDA

-27





dBm

Receiver Reflectance

Rrx



-

-12

dB
