10G 1270 / 1330nm (WDM) 40km BiDi SFP+ Transceiver
SHPP-10G-B40 10Gb/s BiDi optical transceiver inter-converts the 10Gb/s serial electrical data stream with the 10Gb/s optical signal. It complies with SFP+ Multi-Source Agreement (MSA) Specification, 10GBASE Ethernet, SONET OC-192 / SDH and 10G Fibre Channel 1200-SM-LL-L. It provides Digital diagnostics functions via a 2-wire serial interface as specified in SFF-8472. It features hot plug, easy upgrading and low EMI emission. It supports the optical link length of 40km on a single core single mode fiber.
- Supports 9.95Gb/s to 11.3Gb/s bit rates
- Hot-pluggable
- Single LC for Bi-directional Transmission
- SMF link up to 40km
- Built-in 1270/1330 WDM Filter
- Uncooled 1270nm or 1330nm CWDM DFB Laser
- No Reference Clock required
- Built-in digital diagnostic functions
- Power Supply :+3.3V
- Power consumption<1.5W
- Temperature Range: 0~ 70°C
- Very low EMI and excellent ESD protection
- RoHS compliant
10GBASE Ethernet
SONET OC-192 / SDH
10G Fibre Channel
Parameter |
Symbol |
Min |
Typ |
Max |
Unit |
Ref. |
|
Transmitter | |||||||
Bit Rate |
BR |
9.9 |
|
11.3 |
Gb/s |
|
|
Optical Wavelength |
SHPP-10G-B40-23 |
λ |
1260 |
1270 |
1280 |
nm |
|
SHPP-10G-B40-32 |
1320 |
1330 |
1340 |
|
|||
Average output power |
Po |
0 |
|
+5 |
dBm |
|
|
Optical Extinction Ratio |
ER |
3.5 |
|
|
dB |
|
|
Spectral width |
Δλ |
|
|
1 |
nm |
|
|
Side Mode Suppression Ratio |
SMSR |
30 |
|
|
dB |
|
|
Optical Eye Mask |
|
Compliant with IEEE802.3ae |
|
||||
Receiver | |||||||
Bit Rate |
BR |
9.9 |
|
11.3 |
Gb/s |
|
|
Optical Wavelength |
SHPP-10G-B40-23 |
λ |
1320 |
1330 |
1340 |
nm |
|
SHPP-10G-B40-32 |
1260 |
1270 |
1280 |
|
|||
Receiver Sensitivity |
Sen |
|
|
-16 |
dBm |
1 |
|
Maximum Input Power |
PMAX |
0 |
|
|
dBm |
|
|
LOS De-Assert |
LOSD |
|
|
-17 |
dBm |
|
|
LOS Assert |
LOSA |
-27 |
|
|
dBm |
|
|
LOS Hysteresis |
LOSH |
0.5 |
|
4 |
dB |
|
|
Part Number |
Data Rate |
Distance |
Wavelength |
Laser |
Fiber |
DDM |
Connector |
SHPP-10G-B40-23 |
10Gb/s |
40km |
TX1270nm/RX1330nm |
DFB/PIN |
SM |
Yes |
Simplex LC |
SHPP-10G-B40-32 |
10Gb/s |
40km |
TX1330nm/RX1270nm |
DFB/PIN |
SM |
Yes |
Simplex LC |
SHPP-10G-B40-23-SC |
10Gb/s |
40km |
TX1270nm/RX1330nm |
DFB/PIN |
SM |
Yes |
Simplex SC |
SHPP-10G-B40-32-SC |
10Gb/s |
40km |
TX1330nm/RX1270nm |
DFB/PIN |
SM |
Yes |
Simplex SC |
1. How can I pay?
We accept Bank T/T, CASH, ,
2. What's the shipment means?
We can arrange the various shipment means per request.
3. What's the package of the products?
We provide two ways to pack the transceivers:
