High speed metro network SDH/SONET high speed SM LC 2km 40Gb/s QSFP+ module
SHQP-40G-LR4L high performance parallel 40Gbps Quad Small Form-factor Pluggable (QSFP+) optical transceiver offers 4 CWDM transmit and receive lanes, each capable of 10Gbps operation for an aggregate bandwidth of 40Gbps. The central wavelengths of the 4 CWDM channels are 1271, 1291, 1311 and 1331 nm as members of the CWDM wavelength grid defined in ITU-T G694.2. The design is compliant to 40GBASE-LR4 of the IEEE P802.3ba standard. It contains a duplex LC connector for the optical interface and a 38-pin connector for the electrical interface. It is designed with form factor, optical/electrical connection and digital diagnostic interface according to the QSFP Multi-Source Agreement (MSA). It offers very high functionality and feature integration, accessible via a two-wire serial interface.
- 4 independent full-duplex channels
- 11.2Gbps per channel, aggregate bandwidth up to 40Gbps
- Optical connector: duplex LC
- Up to 2km on SMF
- Compliant with QSFP+ MSA
- Complaint with IEEE 802.3ba
- CML compatible electrical I/O
- Power supply: Single +3.3V
- Built-in digital diagnostic functions
- Temperature range 0°C to 70°C
- RoHS Compliant
- Rack to rack
- Data centers
- Metro networks
- Switches and Routers
- Infiniband 4x SDR, DDR, QDR
- Fiber channel
- SDH/SONET
- High speed Ethernet
- Compatible with many switches, such as:
Part Number |
Data Rate |
Distance |
Wavelength |
Laser |
Fiber |
DDM |
Connector |
SHQP-40G-LR4L |
40Gb/s |
2km |
1271/1291/1311/1331nm |
DFB/PIN |
SM |
Yes |
Duplex LC |
Parameter |
Symbol |
Min |
Typ |
Max |
Unit |
Note |
Data Rate per Channel |
|
- |
10.3125 |
11.2 |
Gbps |
|
Power Consumption |
|
- |
2.5 |
3.5 |
W |
|
Supply Current |
Icc |
|
0.75 |
1.0 |
A |
|
Control I/O Voltage-High |
VIH |
2.0 |
|
Vcc |
V |
|
Control I/O Voltage-Low |
VIL |
0 |
|
0.7 |
V |
|
Inter-Channel Skew |
TSK |
|
|
150 |
Ps |
|
RESETL Duration |
|
|
10 |
|
Us |
|
RESETL De-assert time |
|
|
|
100 |
ms |
|
Power On Time |
|
|
|
100 |
ms |
|
Transmitter | ||||||
Single Ended Output Voltage Tolerance |
|
0.3 |
|
4 |
V |
1 |
Common mode Voltage Tolerance |
|
15 |
|
|
mV |
|
Transmit Input Diff Voltage |
VI |
150 |
|
1200 |
mV |
|
Transmit Input Diff Impedance |
ZIN |
85 |
100 |
115 |
|
|
Data Dependent Input Jitter |
DDJ |
|
|
0.2 |
UI |
|
Data Input Total Jitter |
TJ |
|
|
0.65 |
UI |
|
Receiver | ||||||
Single Ended Output Voltage Tolerance |
|
0.3 |
|
4 |
V |
|
Rx Output Diff Voltage |
Vo |
370 |
600 |
950 |
mV |
|
Rx Output Rise and Fall Voltage |
Tr/Tf |
|
|
35 |
ps |
1 |
Total Jitter |
TJ |
|
|
0.2 |
UI |
|
Deterministic Jitter |
DJ |
|
|
0.65 |
UI |
|
Testing
Packagings
Various types of transportation are available, and we will arrange one according to your request.
1. How about your products?
Our products have adopted certifications of CE, FCC and RoHS, which are highly-efficient and at reasonable prices.
2. How about your lead time?
It's 1~3 days for samples and 5~7 days for bulk orders after payments received.
3. How can I pay?
We accept Bank T/T, CASH, Paypal, Western Union...
4. How about your service?
We provide OEM, ODM and excellent after-sale services. If you have any questions, contact us! We provide support 24/7.
