Factory Supply Low Cost Fiber Optical Modules 1000Base-LX 1310nm 20km 1.25G Sfp Module Price photo-2
Factory Supply Low Cost Fiber Optical Modules 1000Base-LX 1310nm 20km 1.25G Sfp Module Price photo-3
Factory Supply Low Cost Fiber Optical Modules 1000Base-LX 1310nm 20km 1.25G Sfp Module Price photo-4
Factory Supply Low Cost Fiber Optical Modules 1000Base-LX 1310nm 20km 1.25G Sfp Module Price photo-5
Factory Supply Low Cost Fiber Optical Modules 1000Base-LX 1310nm 20km 1.25G Sfp Module Price photo-6
US$ 1 - 100 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SH
Model Number:
SHFP-GE-LX
Contact Supplier Request Quote Chat Now
Shenzhen SH Link Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SH
Model Number SHFP-GE-LX

Factory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module price

Product Description



SHFP-GE-LX high performance, cost effective single mode duplex lc 1310nm 20km 1.25G SFP Optical transceiver complies with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). It adopts high-performance 1310nm FP transmitter and high-sensitivity PIN receiver, provides up to 15dB link budge for Gigabit Ethernet applications up to 20km on single mode fiber.

Features
  • Up to 1.25Gb/s Data Links
  • Hot-Pluggable
  • Duplex LC connector
  • 2-wire interface for management specifications compliant with SFF 8472 digital diagnostic monitoring interface
  • Power Supply :+3.3V
  • Power consumption<1W
  • Temperature Range: 0~ 70°C, -40°C to 85°C/-5°C to 85°C available
  • RoHS compliant
Application
  • Metro/Access Networks
  • 1.25 Gb/s 1000Base-LX Ethernet
  • 1G Fibre Channel
  • Other Optical Links
  • Compatible with many switches,such as:

Factory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module price

Ordering Information

Part Number

Data Rate

Distance

Wavelength

Laser

Fiber

DDM

Temperature

Connector

SHFP-GE-LX

1.25Gb/s

20km

1310nm

FP/PIN

SM

Yes

0~ 70°C

Duplex LC

SHFP-GE-LX-E

1.25Gb/s

20km

1310nm

FP/PIN

SM

Yes

-5°C to 85°C

Duplex LC

SHFP-GE-LX-I

1.25Gb/s

20km

1310nm

FP/PIN

SM

Yes

-40°C to 85°C

Duplex LC

SHFP-GE-LX/n

1.25Gb/s

20km

1310nm

FP/PIN

SM

No

0~ 70°C

Duplex LC

SHFP-GE-LX/n-E

1.25Gb/s

20km

1310nm

FP/PIN

SM

No

-5°C to 85°C

Duplex LC

SHFP-GE-LX/n-I

1.25Gb/s

20km

1310nm

FP/PIN

SM

No

-40°C to 85°C

Duplex LC
Specifications

Parameter

Symbol

Min.

Typical

Max.

Unit

Note

Transmitter Section:

Center Wavelength

λc

1270

1310

1360

nm



Spectral Width(RMS)

σRMS





3

nm



Optical Output Power

Pout

-9



-3

dBm

1

Extinction Ratio

ER

8.2





dB



Optical Rise/Fall Time

tr / tf





260

ps

2

Relative Intensity Noise

RIN





-120

dB/Hz



Output Eye Mask

Compliant with  IEEE802.3 z (class 1 laser safety)



Receiver Section:



Optical Input Wavelength

λc

1260



1360

nm



Receiver Overload

Pol

-3





dBm

4

RX Sensitivity

Sen





-24

dBm

4

RX_LOS Assert

LOS A

-35





dBm



RX_LOS De-assert

LOS D





-25

dBm



RX_LOS Hysteresis

LOS H

0.5





dB



General Specifications:

Data Rate

BR



1.25



Gb/s



Bit Error Rate

BER





10-12





Max. Supported Link Length on 9/125μm SMF 1.25Gb/s

LMAX



20



km



Total System Budget

LB

15





dB


Products Show

Factory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module priceFactory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module price

Other Optical Transceiver:

Factory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module priceFactory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module priceFactory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module priceFactory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module priceFactory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module priceFactory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module priceFactory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module priceFactory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module price

Shipping

Various types of transportation are available, and we will arrange one according to your request.

Factory supply Low cost fiber optical modules 1000Base-LX 1310nm 20km 1.25G sfp module price



FAQ

1. Are you a factory?
    Yes, we are a factory.
2. How about your products?
    Our products have adopted certifications of CE, FCC and RoHS, which are highly-efficient and at reasonable prices.
3. How about your lead time?
    It's 1~3 days for samples and 5~7 days for bulk orders after payments received.
4. How can I pay?
   We accept Bank T/T, CASH, Paypal, Western Union...
5. How about your service?
   We provide OEM, ODM and excellent after-sale services. If you have any questions, contact us! We provide support 24/7.
