China Fiber Optical Transceiver Factory 850nm 550M Multimode 1.25Gb/s SFP Module photo-2
China Fiber Optical Transceiver Factory 850nm 550M Multimode 1.25Gb/s SFP Module photo-3
China Fiber Optical Transceiver Factory 850nm 550M Multimode 1.25Gb/s SFP Module photo-4
China Fiber Optical Transceiver Factory 850nm 550M Multimode 1.25Gb/s SFP Module photo-5
China Fiber Optical Transceiver Factory 850nm 550M Multimode 1.25Gb/s SFP Module photo-6
US$ 1 - 100 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SH
Model Number:
SHFP-GE-SX
Contact Supplier Request Quote Chat Now
Shenzhen SH Link Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SH
Model Number SHFP-GE-SX

China fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP module

Product Description



SHFP-GE-SX high performance, cost effective multimdoe duplex lc 1.25G SFP transceiver complies with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). It adopts high-performance 850nm VCSEL transmitter and high-sensitivity PIN receiver, provides up to 9dB link budge for Gigabit Ethernet applications up to 550m on 50/125μm multimode fiber.

Features
  • Up to 1.25Gb/s Data Links
  • Hot-Pluggable
  • Duplex LC connector
  • 2-wire interface for management specifications compliant with SFF 8472 digital diagnostic monitoring interface
  • Power Supply :+3.3V
  • Power consumption<1W
  • Temperature Range: 0~ 70°C, -40°C to 85°C/-5°C to 85°C available
  • RoHS compliant
Application
  • Metro/Access Networks
  • 1.25 Gb/s 1000Base-SX Ethernet
  • 1G Fibre Channel
  • Other Optical Links
  • Compatible with many switches, such as:

China fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP module

Ordering Information

Part Number

Data Rate

Distance

Wavelength

Laser

Fiber

DDM

Temperature

Connector

SHFP-GE-SX

1.25Gb/s

550m

850nm

VCSEL/PIN

MM

Yes

0~ 70°C

Duplex LC

SHFP-GE-SX-E

1.25Gb/s

550m

850nm

VCSEL/PIN

MM

Yes

-5°C to 85°C

Duplex LC

SHFP-GE-SX-I

1.25Gb/s

550m

850nm

VCSEL/PIN

MM

Yes

-40°C to 85°C

Duplex LC

SHFP-GE-SX/n

1.25Gb/s

550m

850nm

VCSEL/PIN

MM

No

0~ 70°C

Duplex LC

SHFP-GE-SX/n-E

1.25Gb/s

550m

850nm

VCSEL/PIN

MM

No

-5°C to 85°C

Duplex LC

SHFP-GE-SX/n-I

1.25Gb/s

550m

850nm

VCSEL/PIN

MM

No

-40°C to 85°C

Duplex LC
Specifications

Parameter

Symbol

Min.

Typical

Max.

Unit

Note

Transmitter Section:

Center Wavelength

λc

840

850

860

nm



Spectral Width(RMS)

σRMS





0.85

nm



Optical Output Power

Pout

-9



-3

dBm

1

Extinction Ratio

ER

8.2





dB



Optical Rise/Fall Time

tr / tf





260

ps

2

Relative Intensity Noise

RIN





-120

dB/Hz



Output Eye Mask

Compliant with  IEEE802.3 z (class 1 laser safety)



Receiver Section:



Optical Input Wavelength

λc

770



860

nm



Receiver Overload

Pol

0





dBm

4

RX Sensitivity

Sen





-18

dBm

4

RX_LOS Assert

LOS A

-29





dBm



RX_LOS De-assert

LOS D





-19

dBm



RX_LOS Hysteresis

LOS H

0.5





dB



General Specifications:

Data Rate

BR



1.25



Gb/s



Bit Error Rate

BER





10-12





Max. Supported Link Length on 50/125μm MMF 1.25Gb/s

LMAX



550



m



Total System Budget

LB

8





dB


Products Show

China fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP moduleChina fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP module

Other Optical Transceiver:

China fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP moduleChina fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP moduleChina fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP moduleChina fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP moduleChina fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP moduleChina fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP moduleChina fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP moduleChina fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP module

Shipping

Various types of transportation are available, and we will arrange one according to your request.

China fiber optical transceiver factory 850nm 550M multimode 1.25Gb/s SFP module



FAQ

1. How about your products?

    Our products have adopted certifications of CE, FCC and RoHS, which are highly-efficient and at reasonable prices.

2. How about your lead time?

    It's 1~3 days for samples and 5~7 days for bulk orders after payments received.

3. How can I pay?

    We accept Bank T/T, CASH, Paypal, Western Union...

4. How about your service?

    We provide OEM, ODM and excellent after-sale services. If you have any questions, contact us! We provide support 24/7.
