Low Voltage Reactive Power Automatic Compensation Device
Product Description
Rated voltage |
660(380)V |
Rated current |
261A~39A;
|
Rated short-time withstand current |
15kA;
|
Capacitor nominal capacity |
400kvar~60kvar |
Protection level |
IP30; |
Compensation mode |
Three phase compensation |
Dimensions |
1200*2200*800mm |
Execution standard |
GB/T 15576-2008<Low-voltage reactive power compensation assemblies |
Low Voltage Reactive Power Automatic Compensation Device
1 |
The device adopts GGD cabinet type, have the characteristics of strong practicability and novel structure;
|
2 |
The inner cabinet is mainly used electrical components with domestic mass production and process stability. Also can be installed the imported components;
|
3 |
Bus bar clamp is hot formed by high strength, high flame retardant PPO alloy, High dielectric strength, Self extinguishing performance;
|
4 |
The structure is made of 8MF cold formed steel with local welding; |
5 |
The cabinet face paint choose electrostatic epoxy powder coating, strong adhesion, good texture, orange gray;
|
6 |
Cabinet protection grade is IP30, Users can also choose between IP30-IP40 based on the use of the environment.
|
High-end equipment/ Low Voltage Reactive Power Automatic Compensation Device
Workshop/ Low Voltage Reactive Power Automatic Compensation Device
We are professional manufacturer of high and low voltage switchgear, mining electrical
equipment, industrial and mining automation system, etc. Meanwhile, the company has
obtained ISO9001 quality management system certificate, ISO14001 environmental
management system certificate, OHSAS18001 occupational health and safety
management system certificate.
Q1.Are you a factory or trading company?
We are factory.
Q2.Does the company provide ODM service for others?
Yes.
Q3:Do you have inspection procedures for your products?
Yes. We have standard inspect procedures, professional inspect device and independent inspect area.
Q4:Can I have a visit to your factory before the order?
Sure, we warmly welcome to visit our factory. If necessary, we will provide reception and accommodation booking services.
Manager Linda
Tel:86-0537-5943069
Mob:+86 18254778162
Address:No.5289, West Outer Ring Road, Zoucheng City, Shandong Province, China
