GGJ AC Low Voltage Reactive Power Auto Compensation Controller

Name: GGJ AC Low Voltage Reactive Power Auto Compensation Controller
Brand: Oriental Electrical
Price: USD $3055.00 - 7279.00 / Set

FOB Price

USD $3055.00 - $7279.00 / Set

1 Set(Min.Order)

Product Details

Place of Origin:

Shandong, China

Brand Name:

Oriental Electrical

Model Number:

GGJ

GGJ AC Low Voltage Reactive Power Auto Compensation Controller

Product Description

Rated voltage	660(380)V
Rated current	261A~39A;
Rated short-time withstand current	15kA;
Capacitor nominal capacity	400kvar~60kvar
Protection level	IP30;
Compensation mode	Three phase compensation
Dimensions	12002200800mm
Execution standard	GB/T 15576-2008<Low-voltage reactive power compensation assemblies

GGJ AC Low Voltage Reactive Power Auto Compensation Controller

1	The device adopts GGD cabinet type, have the characteristics of strong practicability and novel structure;
2	The inner cabinet is mainly used electrical components with domestic mass production and process stability. Also can be installed the imported components;
3	Bus bar clamp is hot formed by high strength, high flame retardant PPO alloy, High dielectric strength, Self extinguishing performance;
4	The structure is made of 8MF cold formed steel with local welding;
5	The cabinet face paint choose electrostatic epoxy powder coating, strong adhesion, good texture, orange gray;
6	Cabinet protection grade is IP30, Users can also choose between IP30-IP40 based on the use of the environment.

Technical Process

High-end equipment/ GGJ AC Low Voltage Reactive Power Auto Compensation Controller

Workshop/ GGJ AC Low Voltage Reactive Power Auto Compensation Controller
