Paste/Jam evporation machine
1. The evaporator can be designed and manufactured according to the exact products from the customer.
2. The continuous low temperature concentration is processing under vacuum situation to ensure the minimum loss of the effective constituent inside.
3. The evaporator main structure is SUS 304 stainless steel, which is composed of tubular heater, vacuum evaporating chamber, Condensate pump, pumps (product recycle pump, feed & outlet pump, vacuum pump, water pump), PLC auto control system, man-machine interface, valves, Instrumentation and gauges, operating platform etc.
4. According to different capacity, we have single-effect evaporator, double-effect evaporator, triple-effect evaporator and multi-effect evaporator for different projects. We can manufacture the evaporating capacity from 1000L to 35000L/hour according to customers’ requirements.
Application scope:
The main type of evaporator will be including the forced circulation evaporator and the falling film evaporator.
The forced circulation evaporator is used for concentrating the fruit paste (tomato paste, peach paste, apricot paste and etc.) and some other products with high viscosity. And the falling film evaporator is used for concentrating products with low viscosity, for example: fruit juice, milk etc
