26*24 T bar channel celing /drywall Roll Forming Machine
- 30 Set / Sets per Month
- Xingang Tianjin
- T/T L/C
Product Details
Condition: | New | Type: | Other, ceiling stud and drywall channel forming machine | Tile Type: | Colored Glaze Steel |
Use: | Wall | Production Capacity: | 10-20m/min | Place of Origin: | Beijing, China |
Brand Name: | Zhongtuo | Model Number: | Roll Forming Machine | Power(W): | 4+4KW |
Voltage: | 380V | Dimension(L*W*H): | 6500*1300*1100 | Weight: | 4.5T |
Certification: | CE/ISO9001 | Warranty: | 12 Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
26*24 T bar channel celing /drywall Roll Forming Machine
This T bar channel ceiling and drywall roll froming machine need to be with the punching system. So according its punching system installing locations, there are half automaticlly ceiling/drywall roll forming machine and full automaticlly ceiling and drywall roll froming machine. The full automaticlly T bar ceilign drywall machine is much expensive comparing with the half automaticlly ceiling/drywall roll froming machine.
but much convenient to operate than the half automaticlly ceiling and drywall roll froming machine.
The T bar ceiling and drywall roll froming machine is to designed with the C U channel machine.
1. pictures for your reference 26*24 T bar channel celing /drywall Roll Forming Machine
2. 26*24 T bar channel celing /drywall Roll Forming Machine
Processing flow diagram of machine
Manual decoiler→→ Feeding material into machine →Roll forming machine →Punching →Measure length →Hydraulic cutting →Finished Products
3. 26*24 T bar channel celing /drywall Roll Forming Machine
Technical parameters
configurations | manual decoiler, guiding platform,main machine of roll forming, cutting device, electric motor,hydraulic station,Delta PLC control system, run out table | ||
Material | Raw material | Galvanized | |
Thickness | 0.3-0.8mm | ||
Manual decoiler | Inner Diameter:450-550mm | Expand by manual | |
Outer Diameter: max 1500mm | |||
Max Coil width:300mm | |||
Capacity: 1.5T | |||
Main Forming machine | Forming steps | 10 rollers | |
Shaft diameter | 40mm | ||
Design type | Memorial arch | ||
roller material | GCr12MoV steel | ||
shaft material | 45# steel | ||
Work speed | 0-25m/min | ||
Transport | By gear | ||
Power of main machine | 3kw | ||
Type of cutting | Hydraulic | ||
Cutting tolerance | ±1mm | ||
Cutter | Gcr12 | ||
Cutter quantity | 1 set | ||
Working pressure | 20MPA | ||
Punching machine | Holes punching machine | 1. Mould material: Gcr12 2. Power supper: Hydraulic Station | |
Hydraulic system | Hydraulic oil | 46# | |
Hydraulic power | 3kw | ||
Cutting length | As required | ||
No distorting or wasting. High level safety factor. | |||
Control Device | control | By PLC | |
PLC language | English and Chinese (or as required) | ||
Brand | Generally Delta, or as your requirement | ||
Function | Automatic length and quantity measurement | ||
Other Spare part | Weight | About 2.5 ton | |
Dimension | 3500*1000*1400mm L x W x H | ||
Main body color | As you need | ||
Voltage | 380v/50hz/3ph(or as required) | ||
Spare cutting blade | One piece for profile | ||
Fuse | 2 pieces | ||
Relay | 2 pieces | ||
Travel switch | 2 pieces | ||
Solenoid valve | 1 pieces | ||
Terms of payment | 1.Terms of payment: 30%T/T ,Balance to be paid before shipping after inspection. 2.Deliver time: 25-30 working days. | ||
Warranty and Training | 1. Warranty: Support the technology all the life. And the machine broken because of quality, we can change the broken part for free within one year.
2. Training: If you come to our factory,we can teach you for free. If you need technician go foreign, the buyer need pay the cost for visa, hotel, ticket, food and others, and buyer need pay the technician USD50/day for salary. There need one technician. Training time will be one week. | ||
4. The photos for 26*24 T bar channel roll froming machine
The T bar roll forming machine can be customized made according to different sizes, the T bar size matching the C U channel roll forming machine. Some customer order the T bar machine with the other machines such as the C channel machine and U channel machine.
