Home > Products > Advertising Caving Machine > 2015 New Type 3030/0303 Mini 3D CNC Router
2015 New Type 3030/0303 Mini 3D CNC Router
USD $2,600 - $6,800
/ Set
1 Set(Min.Order)
- 50 Set / Sets per Month
- Qingdao
- T/T Credit Card PayPal
You May Like
-
engraving cnc router,1325 woodworking cnc router 1300*2500*200
-
engraving and milling machine,1325 woodworking cnc router 1300*2500*200
-
engraver router,1325 woodworking cnc router 1300*2500*200
-
dsp control cnc machine,1325 woodworking cnc router 1300*2500*200
-
cnc woodworking router machine,1325 woodworking cnc router 1300*2500*200
-
cnc woodworking router,1325 woodworking cnc router 1300*2500*200
Product Details
| Condition: | New | CNC or Not: | CNC | Place of Origin: | Shandong, China |
| Brand Name: | WinWin | Model Number: | WW3030A | Voltage: | AC220v, 50/60Hz |
| Power(W): | 2.2KW | Dimension(L*W*H): | 300*00*80mm(Working Area) | Weight: | 110KG |
| Certification: | CE, UL, ISO | Warranty: | 1Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Mini 3D CNC Router Mini Wood Cutter Machine Price
2015 New Type 3030/0303 Mini 3D CNC Router
Product Overviews
1. Overview
The desktop CNC is an affordable CNC work platform. Ideal for any size shop requiring a compact machine to run small routing jobs or to be used as an educational tool. The desktop Routers features ball screw drives on all three axes and is controlled using a DSP easy-to-use hand-held micro stepper controller. The controller can run G-Code or dxf file formats.
2. Materials Cut
Acrylic, ACM, Copper, Brass, Aluminum, PVC, MDF, Melamine plastic, Foam, Melamine, Phenoic, Plywood, HDPE, Solid Surface, Solid Wood, etc.
Product Description
3. Performance parameter
| No | Description | Parameter |
| 1 | X,Y,Z Working area: | 300x300x80 mm |
| 2 | Table Size: | 420x560 mm |
| 3 | Table Surface: | T-slot table |
| 4 | Frame: | Cast Iron Or Cast Aluminum |
| 5 | X, Z Structure: | Round rails and TBI ball Screw, |
| 6 | Y Structure: | Ball Screw, Hiwin Rail Linear Bearings, Table moving |
| 7 | Max. Power Consumption (Without spindle): | 2.2KW |
| 8 | Max. Rapid Travel Rate: | 8000mm/min |
| 9 | Max. Working Speed: | 5000mm/min |
| 10 | Spindle Power: | 0.8kw water cooling spindle |
| 11 | Spindle Speed: | 0-24000RPM |
| 12 | Drive Motors: | Stepper system |
| 13 | Working Voltage: | AC220V/50/60Hz,1 Phs |
| 14 | Command Language: | G Code |
| 15 | Operating System: | DSP System(options: Ncstudio/Mach3 PC Software) |
| 16 | Software Compatibility: | Type3/UcancameV9 software, (Option: Artcam software) |
| 17 | Running Environment Temperature: | 0degree - 45 degree |
| 18 | Relative Humidity: | 30% - 75% |
| 19 | Computer interface: | USB |
| 20 | Flash Memory: | 128M(U Disk) |
| 21 | X,Y,Z Traveling Positioning Accuracy | ±0.01/300mm |
| 22 | X,Y,Z Repositioning Accuracy: | ±0.01 |
| 23 | X,Y Resolution | <0.01mm |
| 24 | Collet: | ER16 |
| 25 | Packing Size: | 800X800X800mm |
| 26 | N.W.: | 85KG |
| 27 | G.W.: | 110KG |
| 28 | Guarantee | One year from the date of commission |
4. Details
5.Samples
Packaging & Shipping
6. Packing&Delivery
Our Services
7. Guarantee & After Sales Service
1.)The machine is guaranteed for 12 months.
2.)Technical support by phone, e-mail or MSN around the clock.
3.)Friendly English version manual and operation video CD disk.
Company Information
8. Factory
9. Contact US
Contact Us
- WinWin Machinery Co., Ltd.(Jinan)
- Contact nameLucy Kang
- Phone86-531-85802660
- AddressRoom 402, Bldg. 48, In No. 170 Yard, Jiluo Rd., Tianqiao District
