XL6436CL Universal Milling Machine

Name: XL6436CL Universal Milling Machine
Brand: YOURONGXILI
SKU: 106420049

US$ 5,000 - 8,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

YOURONGXILI

Tengzhou Xili Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name YOURONGXILI

Model Number XL6436CL

Type Universal

CNC or Not Normal

Voltage 220V/380V

Power(W) 5.5kw

Dimension(L*W*H) 2520*2100*2000

Weight 2800KG

Certification CE ISO

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

XL6436CL Universal Milling Machine

Product Description

1. Professional milling machine with universal horizontal and vertical gear head spindle

2. Solid, heavy cast iron body for vibrationless operations

3. Accurate large and precise ground surface cross table

4. Dovetail slideway in every 3 axes, hand-scraped, providing highest stability and precision.

5. Multifunctional universal milling machine for production factories, toolmakers or workshops at a economical price.

Specification	Unit	XL6436CL
Table size	mm	1600×360
Table travel(X/Y/Z)	mm	1300/320/450
Max. swivel angle of table		45°
Table feed step	grade	8
Table feed range(X/Y/Z)	mm/min	30-750/20-500/15-375
Table rapid speed X	mm/min	1200
Table rapid speed Y	mm/min	800
Table rapid speed Z	mm/min	600
Spindle hole taper		(V)7:24, IS050; (H)7:24, IS050
Arm travel	mm	550
Distance between horizontal spindle center line and table surface	mm	(H)30-420
Distance between spindle nose and table surface	mm	(V)200-590
Distance between spindle center line and arm surface	mm	200
Spindle speed range	rpm	(V)12steps, 60-1750; (H)12steps, 60-1800
T-slots(NO./width/pitch)	mm	3/18/80
Main motor power	Kw	(H)5.5; (V)4
Overall size	mm	2520x2100x2000
Net weight	kg	2800
