Advanced Fly ash AAC Concrete Block Machinery Plant
Basic Introduction of aerated autoclaved brick (block) making machine:
AAC device can take different process according to the category of raw materials, quality and technology characteristics of main equipment and so on.But in general, grind the fly ash or silica sand and water into slurry, adding powdered lime, cement, gypsum and foaming agent, after agitating,then inject into mold frame, quiet foaming and curing, cutting into various specifications of blocks or plates, taken into autoclaved kettle by steam car, formed into porous lightweight aerated concrete products under high temperature and saturated steam curing.
raw material Autoclaved Aerated brick
Cement lime fly ash style aerated block raw material proportion
name |
unit |
Cement lime fly ash |
flash |
% |
65-70 |
cement |
% |
6-15 |
lime |
% |
18-25 |
gypsum |
% |
3-5 |
Aluminum powder paste(600kg/m3) |
1/10000 |
8 |
Water & material rate |
|
0.60-0.65 |
Casting system |
OC |
36-40 |
Aluminum mixing time |
S |
30-40 |
Cement lime Sand style aerated block raw material proportion
Name |
Unit |
Cement Lime Sand |
Sand |
% |
55-65 |
Cement |
% |
10-20 |
Lime |
% |
20-30 |
Gypsum |
% |
2-3 |
Aluminum powder paste(600kg/m3) |
1/10000 |
8 |
Water & material rate |
|
0.65-0.75 |
Casting system |
OC |
35-38 |
Aluminum mixing time |
S |
30-40 |
Shapes and sizes of Autoclaved Aerated brick
Production Process of aerated autoclaved brick making :
According to the category and quality of raw material, and the features of equipment, the aerated concrete can be manufactured in different processes. Generally, add water to ash, silica sand or slag and crush them into slurry; then add powdery lime, cement of right amount, plaster, vesicant, foam stabilizer, and mix and pour it to mould frame; after curing, foaming and hardening, cut it into blocks and boards in different specifications; finally, transport it into pressure steamer with steam-curing cart, and get the light cellular concrete after steam-curing with high temperature and pressure.
Main Equipments in Autoclave Bricks Making
application of autoclaved aerated concrete
Our Services
Pre-sale services: We can provide you with project design, process design, suitable purchase program for your
equipment.Also design and manufacture products based on your specific needs, to train your technical personnel.
Sale: We will accompany you to complete the equipment inspection, construction plan and assist in the development process in detail.
After-Sale Service: We send technicians to the scene to guide the equipment installation, commissioning and training your operating personnel.
Company Overview
Zhengzhou Dongfang Heavy Machinery Co., Ltd is one high tech enterprise, which involves R&D, production, sales and service as well. In the past 20 years, we devote to producing mining equipments, sand making machines and industrial grinding mills, offering expressway, rail way and water conservancy projects the solution of making high grade sand and matched equipments.
If you'v got a brick factory and you want to improve your current formual and save the cost, our professional team are willing to give you the best suggestion and technical support.
If you want to join in this filed, our professional team would like to offer you the best guidance and give you a full appreciation about our machine and the the feasibility of its investment.
We Are Offering AAC Block Plant With Following Annual Capacity:
50,000 m3 AAC Block Plant; 60,000 m3 AAC Block Plant;
100,000 m3 AAC Block Plant; 150,000 m3 AAC Block Plant;
200,000 m3 AAC Block Plant; 250,000 m3 AAC Block Plant;
300,000 m3 AAC Block Plant; 350,000 m3 AAC Block Plant;
400,000 m3 AAC Block Plant; 450,000 m3 AAC Block Plant
We sincerely welcome you to visit our factory and discuss the feasibility of cooperation.
If you are interested in our Advanced Fly ash AAC Concrete Block Machinery Plant ,please feel free to contact with us at any time
Contact person: Rebecca Hong
Tel : +86-371-67944555
Fax: +86-371-67944555
