3kw Open Frame Air Cooled Diesel Generator-KOOP
USD $300 - $500
/ Set
5 Sets(Min.Order)
- 1000 Set / Sets per Month
- SHANG HAI
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | KOOP | |
| Model Number | KDF4000X | Output Type | AC Single Phase | |
| Speed | 3000/3600 | Frequency | 50/60 | |
| Rated Power | 2.8 | Rated Voltage | 220V | |
| Rated Current | 12.7A |
Product Description
Specifications
1.Air Cooled Single Cylinder Diesel Generator2.Portable and Easy Maintance
3. CE Certificate
4. Longer service Life
Professional Manufacture Factory of High Quality Air Cooled Diesel Engine, Generator and Water Pump for many years
| KOOP Air Cooled Diesel Generator | ||||
| Model | KDF4000X/XE | KDF6700X/XE | ||
| Rated Frequency(Hz) | 50 | 60 | 50 | 60 |
| Rated Voltage(V) | 220,230,240,110/220,115/230,120/240,220/380 | |||
| Rated Output(KVA) | 2.6 | 3 | 4.5 | 5 |
| Max Output(KVA) | 3 | 3.3 | 5 | 5.5 |
| Rated Rotation Speed(rpm) | 3000 | 3600 | 3000 | 3600 |
| Power Factor(Cos¢) | 1/0.8 | |||
| Phase Number | Single/Three | |||
| Fuel Consumption(g/KW.h) | 370 | 340 | ||
| Fuel Tank Capacity(L) | 12.5 | |||
| Continuous Running Time(hr) at rated power | 14 | 7 | ||
| Noise Level(dBA@7m)(Zero Load~Full Load) | 72~77 | 75~79 | ||
| Starting System | X:Recoil Starter;XE:Electric Starter | |||
| Fuel Type | 0#(Summer),-10#(Winter),-35#(Chill Cold)Diesel Oil | |||
| Lube | SAE10W30(above CD Grade) | |||
| Engine Model | X:KD178F | X:KD186FA | ||
| XE:KD178FE | XE:KD186FAE | |||
| Engine Type | 1-Cylinder,4-Stroke, Air Cooled,Vertical,Diesel Engine | |||
| BorexStroke(mm) | 78x62 | 86x72 | ||
| Displacement(cc) | 296 | 418 | ||
| Compression Ratio | 20:01 | 19:01 | ||
| Rated Power(KW/RPM) | 3.7/3000 | 4.0/3600 | 6/3000 | 6.6/3600 |
| Overall Dimension(mm)(LxWxH) | 685x470x570 | 735x485x620 | ||
