Help CenterPP Parker Pneumatic Seals
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Style:
Pneumatic
Material:
PU
Payment & Shipping
Payment Methods:
Port of Shipment:
China all ports
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard or Nonstandard
Standard
Style
Pneumatic
Material
PU
Place of Origin
Zhejiang, China
Brand Name
AILATE
PP Pneumatic cushioning seal is specially designed for cushioning spears in pneumatic cylinders.
Advantages
-As the seal function as a check valve, no separate valve is necessary;
-Optimum use of design-related cushion travel;
-High cushioning consistency due to automatic centering, even in the case of misalignment of the cushioning spear to the cylinder head;
-Increase reliability due to two independent sealing systems(flexible sealing lips and axial sealing areas);
-Easy installation.
-Optimum use of design-related cushion travel;
-High cushioning consistency due to automatic centering, even in the case of misalignment of the cushioning spear to the cylinder head;
-Increase reliability due to two independent sealing systems(flexible sealing lips and axial sealing areas);
-Easy installation.
Technical Data
-Pressure: ≤ 1.6Mpa;
-Temperature: -35~+80° C;
-Speed: ≤ 1.0m/s;
-Media: Lubricated as well as dry and oil-free air (after initial lubrication during assembly).
-Temperature: -35~+80° C;
-Speed: ≤ 1.0m/s;
-Media: Lubricated as well as dry and oil-free air (after initial lubrication during assembly).
Material
-Material: TPU;
-Hardness: 90-94 Shore A;
-Color: Green.
-Hardness: 90-94 Shore A;
-Color: Green.
|
