Home > Products > Mechanical Shearing Machine > Mechanical shearing machine
Mechanical shearing machine
USD $2,600 - $7,900
/ Piece
1 Piece(Min.Order)
- 50 Piece / Pieces per Month
- Shanghai China
- T/T
You May Like
-
Omax Maxiem Pump Minor Maint 302700 Retainer Man 301873 301353 Ring Seal 303274 Major Maintenance Kit
-
Dual Port Swivels Seal Replacement Kit 308616 Package for Omax 308620-1 2 3
-
60KPSI SL-IV SL-V WK000216 05007786 Bushing Retainer Flange for KMT Water Jet Cutting
-
Waterjet Spare Parts 90K WK000190 189 20468617 20475871 Pneumatic Dump Valve
-
1-14493 UHP 90 degree 1/4 in. 94k Waterjet Repair Kit 015093-1 Swivel Rebuild Kit for Water Jet Cutt
-
Hydraulic Waste Car Body Shell Gantry Shear Machine for Scrap Recycling Center
Product Details
| Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | LIWANG |
| Model Number: | Q11-3X1500 | Rated Power: | 7.5kw | Weight: | 1700kgs |
| Certification: | ISO CQC | Warranty: | 12 Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Mechanical Shearing Machine
Features
Main parameters of Q11 mechanical shearing machine
Model | Q11-3X1300 | Q11-3X1500 | Q11-4X2000 | Q11-4X2500 | Q11-4X3200 | Q11-4X4000 | Q11-6X2500 |
Max. Shearing Thickness(mm) | 3 | 3 | 4 | 4 | 4 | 4 | 6 |
Max. Shearing Width(mm) | 1300 | 1500 | 2000 | 2500 | 3200 | 4000 | 2500 |
Shear Angle | 2°14′ | 2°25′ | 1°30′ | 1°30′ | 1°30′ | 1°30′ | 2° |
Number of Stroke(min-1) | 20 | 20 | 20 | 20 | 20 | 20 | 24 |
Back gauge(mm) | 350 | 350 | 500 | 500 | 500 | 500 | 500 |
Height of worktable(mm) |
|
|
|
|
|
|
|
Motor Power(kw) | 3 | 3 | 4 | 5.5 | 7.5 | 7.5 | 7.5 |
Net Weight(kg) |
|
|
|
|
|
|
Contact Us
- Nantong Liwang Machine Tool Co., Ltd.
- Contact nameTing Ting Xu
- Phone86-0513-88283334
- AddressLibao Town, Haian County Nantong,Jiangsu
