Help CenterCNC-WC67K-400/4000 Aluminum Bending Machine
Related Products
-
Q11 Series Mechanical Shearing MachineNegotiableMOQ: 1 Piece -
Specialized High-speed ShearNegotiableMOQ: 1 Piece
-
QH11D Serier Precision Mechanic ShearUS$ 1,000 - 4,000MOQ: 1 Piece
-
QH11D Mechanical Shearing MachineUS$ 1,000 - 4,000MOQ: 1 Piece
-
QH11D 2.5X1250 Mechanical Shearing MachineNegotiableMOQ: 1 Piece
Main parameters
Nominal pressure: 4000KN
Worktable length: 4000mm
Distance between uprights: 3100mm
Throat depth: 400mm
Cylinder Stroke: 300mm
Main motor power: 30kw
Oil pump: 32 Mpa
Over dimension: 4200mmx2300mmx3380mm(LxWxH)
Character
--Beautiful appearance. European design standard and manufacturing process.
--The vertical cloumns, top slide and lower worktable are bored integrally to ensure machining
precision.
--Time delay function with bottom stop to ensure workpiece precision.
--Large stroke with the slide, high parallelism tolerance on both sides.
--The angle accuracy up to ±30′.
--Steel-welded structure, vibration to relieve stress, high strength and good rigidity.
--The stopper driven and controlled by servo motor, fast, stable, high precision and low noise.
--Hydraulic top-drive, steadiness and reliable.
--Mechanical stop and steel torsion bar to maintain synchronization and high precision.
--Electric control and manual fine-tuning mode are adopted for distance of rear stopper and stroke
of sliding block, and fitted with digital display device, easy and quick in use.
--Deflection compensation unit on worktable ensure bending accuracy.
Electrical control system
--Main electrical elements are from aboard and complies with international standard. They are safe and reliable, long life, and with good anti-interference ability. The electrical cabinet has heat dissipation function.
--Portable pedal switch with emergency power off function
