ironworker, hydraulic ironworker, hydraulic universal ironworker
- 60 Piece / Pieces per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
- CNC machine tool Oil Lubrication products and equipment
- Centralized Lubrication System Pump for Machinery
- automatic pump control oil machine maintenance lubricators
- electronic products machinery manufacturing lubrication solutions
- cnc turning electric motor machine parts and lubrication pump
- Centralized Lubrication system industrial machinery equipment
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | LIWANG | Model Number: | DIW-90E |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
hydraulic universal ironworker
DIW-90 series Hydraulic Ironworker is widely used in steel structure, high voltage tower, telecommunication tower, large rigid frame bridge, military and air craft and other metal fabricating industries. It also can be used in vocational school for teaching purpose.
The Ironworker featuring multiple functions, including: punching all kinds of holes (round hole, square hole, oblong hole), louver punching, profile steel shearing (channel shearing, I-beam shearing, round/square bar shearing, T-bar shearing, steel plate shearing, angle steel shearing), notching, press brake, angle bending. We can design any special tools according to your metal fabricating requirements.
Free standing on suitable floor, the ironworker machines just require electrical connection to be ready for work. For two operator utilization, the hydraulic system is activated by two shielded for switch control, one operating the punching end cylinder, the other operating shearing end cylinder, the shear cylinder provides the power to three shearing stations and notching station.
No. | Function | Item | Unit | DIW-90E/L | |
1 | Shearing Plate | Angle of shearing | ° | 8° | 8° |
Max shearing thickness | mm | 20 | 20 | ||
Flat bar | (W×T) mm | 10×480 | 10×480 | ||
20×330 | 20×330 | ||||
2 | Shearing bar | Round steel | mm | 50 | 50 |
Square steel | mm | 45×45 | 45×45 | ||
90° shearing of equal-angle steel | mm | 140×140×12 | 140×140×12 | ||
45° shearing of equal-angle steel | mm | 70×70×10 | 70×70×10 | ||
90° shearing of T-bar | mm | 140×70×12 | 140×70×12 | ||
I-beam steel | mm | 160×86×6 | 160×86×6 | ||
Channel steel | mm | 160×160×6.5 | 160×160×6.5 | ||
3 | Notch | Thickness | mm | 10 | 10 |
Width | mm | 80 | 80 | ||
Depth | mm | 100 | 100 | ||
4 | Punching hole | Max. punching thickness | mm | 20 | 20 |
Max. diameter of punching | mm | 30 | 30 | ||
Punching pressure | mm | 90 | 90 | ||
Depth of throat | mm | 355 | 355 | ||
Max. length of cylinder stroke | mm | 80 | 80 | ||
Stroke times | Times/min | 8 | 8 | ||
5 |
| Material strength | N/mm ² | ≤450 | ≤450 |
6 |
| Motor power | KW | 5.5 | 7.5 |
7 |
| Overall dimensions | L×W×H | 1950×900×1930 | 1950×1120×1930 |
8 |
| Net. weight | KG | 2600 | 2800 |
Features
Name | Features |
Electric Cabinet | Cabinet-open power off and 24V safety Voltage offer overall protection to the electric elements and working labors |
Cooling system | Machines are equipped with automatic temperature controlling system, monitoring and controlling the temperature of hydraulic oil in a very stable status, meanwhile protect the tightness of the seals, high-rise the producing effectiveness. |
Valve | Machines adopt high-qualified hydraulic valve groups to ensure the strength and credibility. |
Motor | High quality motor and universal inner filter can ensure easy maintenance and replacing. |
Punching Position | Above and below dies can be changed quickly. |
Porous Punch | All kinds of punching dies to be exchanged, it can make all kinds of holes on angle steel, profiled steel and plates |
Plate Shearing | The design adopts automatic holding system for quicker plate shearing. greatly improving the time effectiveness. |
Angle Shearing | The design installs humanized and high-efficiency automatic holding system, saving the working labors and rising the producing efficiency. |
Shearing and Notch Position | Special design can excellent cut right-angle, bevel and notch on the angle steel, profiled steel and plates. |
Back Gauge | Automatic stop gauge can be adjusted in accordance with the shearing length, can control efficient shearing length automatically |
Profile Shearing | Square bar shearing, round bar shearing, angle shearing, C-channel shearing, I beam shearing |
Dies | All kinds of punches and dies can satisfy client’s processing requirements |
bending | Multi V bending dies can be exchanged with the V dies below |
Louver Punching | Louver punching |
hydraulic universal ironworker
