CNC Engraving Glass Machine for bathing appliance glass
- 100 Set / Sets per Month
- Ningbo/Shanghai
- T/T
- CE glass screen print machine for gas cooker glass
- CE glass screen print machine for furniture glass
- CE glass screen print machine for bathing appliance glass
- CE glass screen print machine for table glass
- CE certificate CNC Glass Cutting Machinery for automotive glass
- CE certificate CNC Glass Cutting Machinery for furniture glass
Product Details
Condition: | New | Machine Type: | Engraving Machine / CNC Router | Place of Origin: | Zhejiang, China |
Brand Name: | LIDU | Model Number: | LDKE3016 | Voltage: | 380V |
Power(W): | 21Kw | Certification: | Other, CE, ISO9001:2000/CE | Warranty: | 12 months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
cnc engraving glass machine1.easy operation
2,high effect
3,high percision
4.CE certificate
CNC engraving glass machine for bathing appliance glass in the factory
Brief introduction of CNC engraving glass machine for bathing appliance glass
This CNC Engraving Machine is a new equipment for glass deep processing. It adopts CAD system and is designed by several senior engineers together. It is widely used in notching and polishing in glass and mirror.
The whole processing procedure from pattern design to processing is controlled by computer. We can equip tool library and change tool system according to customers' requirements.
-------------------------------------------------------------------------------------------------------
Delivery site of CNC Glass engraving glass machine for bathing appliance glass
Main features of CNC engraving glass machine for bathing appliance glass
1. Fast processing. The max. speed of the air knife of axis X can reach 60 m/min.
2. Unique international pattern simulating function makes the processing patterns more visible, thus failure has been decreased greatly.
3. Wide using range of grinding wheel: from Φ110 to Φ170, this is twice of the same products in China. The producing cost has been reduced greatly.
4. Both Chinese & English interface. It is easy to learn and operate.
-------------------------------------------------------------------------------------------------------
Technical Parameters of CNC engraving glass machine for bathing appliance glass :
Technical Parameters of CNC Glass Engraving Machine :
Model | LDKE2512 | LDKE3016 | LDKE3019 |
Table Size(mm) | 2500×1200 | 3000×1600 | 3000×1900 |
Stroke of Axis x,y,z(mm) | 2500×1200×155 | 3000×1600×155 | 3000×1900×155 |
Rotating Angle of Axis | 0~360° | 0~360° | 0~360° |
Allocating Accuracy(X,Y,Z) | 0.01×0.02×0.01 | 0.01×0.02×0.01 | 0.01×0.02×0.01 |
Allocating Accuracy of Axis C | 5’’ | 5’’ | 5’’ |
Repeatability(mm) | 0.005×0.01×0.005 | 0.005×0.01×0.005 | 0.005×0.01×0.005 |
Axis C | 2’’ | 2’’ | 2’’ |
Velocity(Axis X.Y)(m/min) | 60 | 60 | 60 |
Speed of Axis Z(m/min) | 30 | 30 | 30 |
Quantity of Knives (PCS) | 10 | 10 | 10 |
Rotating Speed of Main Spindle Speed(rpm) | 0-6000 | 0-6000 | 0-6000 |
CNC System | USA | USA | USA |
Main Spindle Power(KW) | 4 | 4 | 4 |
Max Width of Slot(mm) | 30 | 30 | 30 |
Glass Thickness(mm) | 3-30 | 3-30 | 3-30 |
Max.Diameter of Grinding Wheel(mm) | 170 | 170 | 170 |
Total Power (kw) | 18 | 21 | 22 |
OUR SERVICE
Your inquiry related to our product & price will be replied within 24hours.
Well-trained & experienced staff are to answer all your inquiries in English of course.
Working time: 9:00am - 6:00pm, Monday to Friday (UTC+8).
OEM & ODM projects are highly welcomed. We have strong R&D team here to help.
Your business relationship with us will be confidential to any third party.
Good after-sale service offered, please get back if you got question.
For more details, please feel free to contact us. We will be more than happy to help in anyway we can.
Final producs of CNC engraving glass machine for bathing appliance glass
