Specifications
Advanced control and higher efficiencyEnergy Saving
Environmental Friendly
Certification ISO9001:2000/CE
mini Glass Tempering Furnace Series
This series of Glass Tempering Furnace is widely used for producing tempered glass for architecture decoration, home furniture and home appliance. It adopts advanced computer controlling technology. It also can diagnose and deal with failure from long-distance through internet.
Characteristics
1 . Stepping loading. Stepping length can be set automatically according to glass size.
2. Automatic length detecting device. It can adjust the reciprocating route and the cycle of the glass in the heating furnace and air diffuser according to glass loading size.
3. Touch screen human-computer interface. The main controlling system adopts Japanese Mitsubishi elements. Computer adopts Japanese Mitsubishi color touch screen. All the parameters can be modified online. Parameter of glass with different thickness can be input, saved and called by order form..
4. The furnace adopts the international latest heat preservation technology. The heat preservation system has the same life span with the furnace. SCR triggers when over zero which is no pollution to power net.
5. Quartz roller with larger diameter prolongs the life span and enhances the heat preservation capacity.
6. Heat balance system distributes the temperature inside the furnace evenly.
7. The blower is controlled with inverter completely, so that it can reduce power consumption
Mainly in
High grade domestic appliances, interior decorations, automobile, trains, ships, flat tempered laminated glass for architecture, etc.
Parameters
| Model | Max.size | Min.size | thickness | output(m2/h) | power |
| LDGN1302 | 1300x200 | 40x40 | 2.85-12 | 5.2 | 60 |
| LDGN2003 | 2000x300 | 50x50 | 2.85-12 | 11.7 | 100 |
| LDGN2006 | 2000x600 | 100x50 | 2.85-12 | 23.6 | 260 |
| LDGN2009 | 2000x900 | 140x50 | 2.85-12 | 35.1 | 350 |
| LDGN3010 | 2.85-12 | 56.1 | 420 |
Remark
All sizes are based on millimeter and the capacity subjected to 5mm glass at 80% utilization and 100% end-product rate. The change of equipment configuration will be in accordance with the different of glass thickness range,it is depended on actual design.
