Glass Machinery for Engraving Machine

Glass Machinery for Engraving Machine thumbnail-1
Glass Machinery for Engraving Machine photo-1
US$ 10,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Engraving Machine / CNC Router
Place of Origin:
Zhejiang, China
Contact Supplier Request Quote Chat Now
Haining Lidu Glass Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Machine Type Engraving Machine / CNC Router
Place of Origin Zhejiang, China
Brand Name Lidu
Model Number LDKW2815
Voltage 220v/380v
Power(W) 26kw
Dimension(L*W*H) 5500x2500x2650mm
Weight 8ton
Certification Other, CE, ISO9001:2000
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.CNC Glass Working Center
2.Stationary system
3.High processing speed
4.Computer control CNC system
5.CE certificate

 glass machinery CNC glass engraving machine LDKW2815





Characteristics:



       This machine adopts CNC system to control axis X, Y, Z and the main axis of the engraving machine. There is automatic control on lubrication, vacuum, hydraulic pressure, and water supply, also, it has the function of protection and alarm. It is widely used in grinding, cutting, engraving, drilling and polishing glass and mirror.

       The whole procedure from pattern design to processing is controlled by computer. It can equip tool library and tool changing system according to requirements. Its advantages are: stationary system, high processing speed and low price.



glass machinery for engraving machine



glass machinery for engraving machineglass machinery for engraving machineglass machinery for engraving machineglass machinery for engraving machineglass machinery for engraving machineglass machinery for engraving machine











Technology parameters:



Model

LDKW4525

Table Size(mm)

4500×2500

Stroke of Axis x,y,z(mm)

4500×2500×250

Allocating Accuracy(X,Y,Z)

0.01×0.02×0.01

Repeatability(mm)

0.005×0.01×0.005

Velocity(Axis X.Y)(m/min)

15-35

Speed of Axis Z(m/min)

30

Rotating Speed of Main Spindle Speed(rpm)

0-9000

Main Spindle Power(KW)

7.5

Glass Thickness(mm)

2-30

Max.Diameter of Grinding Wheel(mm)

160

Total Power (kw)

28









Country of origin:  China

Delivery time:  Within 60 working days since the day we get payment information form our bank

Terms of Payment:

30% T/T as down payment

60% T/T when machine complete and before delivery

10% by T/T within 15 days since the day that installation is ok
