Help CenterMini Flat Glass Tempeing Furnace/LDGN2006
Related Products
Specifications
1.Temper glass with thickness 2.85-19mm, width 1600mm2.Controlled with inverter
uce power consumption
Mini flat glass tempering furnaces/ /LDGN2006
It can process glass of diameter 40 mm and thickness 2.5mm with good flatness after tempering .It also can process intensified glass with thickness 1.8mm.
Characteristics
1. The furnace can temper 2.85mm glass.
2. It can temper glass with 2.85mm---19mm in thickness, 1600mm in width.
3. The blower is controlled with inverter completely, so that it can reduce power consumption.
Mainly in
This machine is specially used for producing high-quality super thin ,super small or super big flat tempered industrial instruments, home appliance, lamps and lantern decorations, architecture decorations ,and also tempered and laminated glass.
Parameters
Type |
Max.Glass Size(mm) |
Min.Glass Size(mm) |
Glass Thickness(mm) |
Capacity (m 2/h) |
Installation Power(kw) |
LDGN1302 |
1300×200 |
40×400 |
2.85-12 |
5.2 |
60 |
LDGN2003 |
2000×300 |
50×50 |
2.85-12 |
11.7 |
100 |
LDGN2006 |
2000×600 |
100×50 |
2.85-12 |
23.6 |
260 |
LDGN2010 |
2000×900 |
140×50 |
2.85-12 |
35.1 |
350 |
LDGN3010 |
3200×900 |
140×50 |
2.85-12 |
56.1 |
420 |
Remark
All sizes are based on millimeter and the capacity subjected to 5mm glass at 80% utilization and 100% end-product rate. The change of equipment configuration will be in accordance with the different of glass thickness range,it is depended on actual design.
Country of origin: China
Delivery time: Within 60 working days since the day we get payment information form our bank
Terms of Payment:
30% T/T as down payment
60% T/T when machine complete and before delivery
10% by T/T within 15 days since the day that installation is ok
