Help CenterPesky-Martens Closed Cup Flash Point Tester
Related Products
-
Petroleum Products Pesky-Martens Closed Cup Flash Point TesterUS$ 100 - 950MOQ: 1 Set -
Petroleum Closed Cup Flash Point Pesky-Martens Auto Testing MachineUS$ 100 - 950MOQ: 1 Set
-
Petroleum Products (pensky-martens Closed Cup Methods) GB/T261 ASTM D93 ISO 2719 Flash Point Test MethodsUS$ 100 - 950MOQ: 1 Set
-
Rapid Low Temperature Closed Cup Flash Point Tester InstrumentUS$ 1,000 - 10,000MOQ: 1 Set
-
FDT-0234 Rapid Low Temperature Closed Cup Flash Point TesterUS$ 1,000 - 10,000MOQ: 1 Set
Specifications
GB/T3536-2008 ASTM D93,ISO259
china manufacture for Petroleum Test Equipment Petroleum Test InstrumentsaaOil Test Centrifuges
FDT-0201 Pesky-Martens Closed Cup flash point tester Application range
It fully conforms to the GB/T261 ASTM D93 ISO 2719 IP34 Test Methods for closed flash point tester of Petroleum Products (Pensky-martens closed cup Methods), Test Method For flash point determinations of fuels, lubricating oils, liquids containing suspended solids and liquids that tend to form a surface film during testing. Features and Benefits • Conforms to ASTM D93 and related specifications • Simple automation routine for easy operation
Features
1, with the operating software prompts;
2, with the experimental date, test time parameter prompts;
3, automatic correction of atmospheric pressure and calculated correction values;
4 differential detection, automatic correction system deviation;
5, opening the lid, ignition, detection, print test data computer is done automatically;
6, electronic ignition, the gas flame, forced air cooling.
7, The innovative use of the furnace automatically tilt system, the experiment after the furnace cooling rate faster, greatly shortened several times the time interval between experiments
Specifications
1 Power supply: AC 220V ± 10%, 50Hz.
2, Heating device: heating power continuously adjustable from 0 ~ 600W.
3, sample Heating rate: 1 ~ 12 °C/ min, controllable adjustable.
4, electric mixing device: 90 ~ 120 rpm / min, for the test procedure A.
5, 250 ± 10 rev / min, for the test procedure B.
6, Standard Oil Cup: diameter: 50.7 ~ 50.8 mm.
Depth: 55.7 ~ 56.0 mm.
Test oil capacity groove depth: 33.9 ~ 34.3 mm.
Test oil capacity: approximately 70 ml.
7, ignition device: ignition sources: gas (or other civil combustible gas, the same below). Ignition device diameter: 0.8 mm.
8, Thermometer: rod mercury Thermometer, in line with GB / T 261-2008 standard.
Measuring range -5 ~ 110 °C, dividing 0.5 °C.
Measuring range 20 ~ 150 °C, dividing 1.0 °C.
Measuring range 90 ~ 370 °C, division 2 °C.
9, ambient temperature: 35 °C.
10, Relative humidity: 85%.
11, Power consumption: less than 650W.”
Reid Method Vapor Pressure Analyzer FDR-0271
Automatic oxidation stability tester of petroleumFDR-0181
