Help CenterCleveland Open Cup (COC) Flash Point Tester,crude Petroleum Ignition Testing Equipment
Related Products
-
Crude Petroleum Flash Point and Ignition Testing EquipmentUS$ 200 - 10,000MOQ: 1 Set -
ASTM D92 Crude Oil Cleveland Open Flash Point Tester and Ignition InstrumentUS$ 200 - 10,000MOQ: 1 Set
-
Raw Petroleum Flash Point and Fire Point Test Equipment Astm D92US$ 200 - 10,000MOQ: 1 Set
-
Automatic Pensky-martens Closed Cup Flash Point TesterUS$ 1 - 10,000MOQ: 1 Set
-
Pensky-martens Closed Cup Flash Point Tester,ISO 2719 Closed Cup Flash Point InousmaterialsUS$ 1 - 10,000MOQ: 1 Set
Applied standards:
GB/T3536, ISO2592, ASTM D92
Application range
the instrument is designed and manufactured in accordance with the requirements stipulated by the People’s Republic of standard GB/T3536 “”petroleum products Determination of flash and Fire points - Cleveland open cup method””, applicable to the determination in addition to fuel oil and opening a flash point of less
than 79 °C. flash and Fire points of petroleum products and asphalt.
Function Features
1, Using a special form of the heating furnace, to ensure the security of the test; heating power is continuously
adjustable to meet the requirements of the test.
2, instrument is designed for desk FRIEND structure, stainless steel counter FRIENDs and stainless steel furnace shell,
nice.
3, instrument is complete, users only accompanied by gas or other civil combustible gas can be tested.
4, with the the flame extinguished cover, ignition test requirements.
Technical Specification
1 Power supply: AC 220V ± 10%, 50Hz.
2. Heating device: quartz tube furnace heating, no open flame, explosion-proof, power 0 ~ 600W continuously adjustable.
3 zoned sweeping device: automatic scanning program.
4, thermometer: -6 to 400 °Cindexing 2°Cthe technical conditions are met petroleum products testing the liquid thermometer technical conditions GB/T514.
5 ignition: ignition sources: gas (or other civil combustible gas, the same below);
6 vents Aperture: 0.6 to 0.8 mm.
Ambient temperature: -10 °C~ 50 °C
7, Relative humidity: 85%.
8 Total power consumption: not more than 650W.
open cup flash point series |
|
|
|
||
Model |
FDT-0101 |
FDT-0131 |
FDT-0132 |
FDT-0172 |
FDT-0192 |
Standards |
ISO2592,ASTM D92 |
||||
Range |
ambient~360℃ |
ambient~400℃ |
ambient~400℃ |
ambient~400℃ |
ambient~400℃ |
Repeatability |
≤4℃ |
≤4℃ |
≤4℃ |
≤4℃ |
≤4℃ |
Reproducibility |
≤6℃ |
≤6℃ |
≤6℃ |
≤6℃ |
≤6℃ |
Automatic up/down |
N |
Y |
Y |
Y |
Y |
Display |
N |
BlueScreen |
Color screen |
||
Automatic detect |
N |
Y |
Y |
Y |
Y |
Detect Fire point |
N |
N |
Y |
N |
N |
with microprinter |
N |
Y |
Y |
Y |
Y |
Sample cup |
1 |
1 |
1 |
3 |
6 |
Ignition source |
gas |
Electronic ignition,gas flame |
|||
learn more(click--) |
FDT-0101 |
FDT-0131 |
FDT-0132 |
||
