Help CenterHigh Quality ASTM D36 Automatic Bitumen Softening Point Tester
Related Products
-
High Qualitywax Content of Asphalt TesterUS$ 2,000 - 3,200MOQ: 1 Set -
High Quality Petroleum Bitumen Component TesterUS$ 2,000 - 8,100MOQ: 1 Set
-
High Quality Asphalt Rolling Thin Film OvenUS$ 2,000 - 5,700MOQ: 1 Set
-
Ash Content Test Equipment ;ash Content Testing ;ash Content TesterUS$ 1,000 - 2,700MOQ: 1 Set
-
Automatic Bitumen Needle Penetration TesterUS$ 100 - 9,700MOQ: 1 Set
Specifications
Standard:ASTM D361.automatically test
2.easy to operate
3.we are manufacturer
4.high precision
Application range
Automatic Bitumen Softening Point Tester is designed and made as per the National Standard GB/T4507 “Test Methods for Softening Point of Asphalt” andT0606 “Asphalt Softening Point Test (Ring andBall Methods)” in the Industry Standard JTJ052 Specification and test Methods of Bitumen andBituminous Mixture for Highway Engineering. It is suitable to determine softening point of petroleum asphalt, coal pitch, liquid petroleum asphalt, andother asphalts. It is the desired instrument for asphalt manufacturing companies, Highway andbridge construction companies, colleges anduniversities, scientific research institutes.
Features
Automatic Bitumen Softening Point Tester adopts computer for control, electron photo-electricity for measurement, andLCD for display. The test data can be printed out by a micro-printer. It has characteristics of linearity heating, anduniform stirring. It can also make determination for two samples or four samples (the default is for four samples) at the same time andit can determine the softening point automatically. It is Highly automatic, convenient, rapid, and reliable. It is the intelligent instrument for softening point determination.
| Packaging Detail: | standard export case |
| Delivery Detail: | 20 working days after receipt of the advance payment. |
warranty: 12 month
Friend has always adhere to the alliance strategies with customer unit development, and integrate enterprise resource advantages,with the pursuit of excellence in product quality, innovative and pragmatic attitude to customer needs and to provide professional pre-sales,
after-sales service.
Since the establish of Friend,it uphold the Western industrial civilization "artisan spirit" as the ideas, and constantly improve our products, and continuously improveour processes to meet market demand, and strive to create a new management models and new products to meet customer growing needs.
Asphalt series
|
FDL-0131 |
FDL-0171 |
FDL-0231 |
FDL-0271 |
FDL-0301 |
FDL-0331 |
Standards |
GB/T4507,ASTM D36,T0606 |
GB/T4508 T0605 |
GB/T4508 T0605 |
T0604 ,GB/T4509, ASTMD5 |
GB/T4509 ,T0604 |
|
Power supply |
AC220V / 50Hz |
AC220V / 50Hz |
AC220V / 50Hz |
AC220V / 50Hz |
AC220V / 50Hz |
AC220V / 50Hz |
temperature range |
5.0 ℃ ~ 90 |
32 ℃ ~ + 160 ℃,+ 5 ℃ ~ + 80 ℃ |
5 ~ 49 ℃, adjustable |
5 ℃ ~ 50 ℃ |
25±0.1℃ |
25 ± 0.1 ℃ |
Temperature Resolution |
0.01 ℃ |
0.01 ℃ |
|
|
|
0.1 Penetration |
heating power |
800W |
|
3000W |
|
220W |
200W |
beaker effective volume |
1000ml |
|
|
|
|
|
relative humidity |
≤85% |
≤85% |
|
|
|
|
Power consumption |
less than 850W |
less than 750W |
less than 4100W |
|
|
|
Dimensions |
|
360*280*490 |
|
|
|
|
measurement range |
|
|
1.5m (± 10mm) |
2.0m (± 10mm),0 ~ 300N |
500 Penetration |
0 to 600 penetration |
|
Automatic asphalt softening point tester |
Asphalt extend Tester |
Automatic extension of asphalt tester |
Asphalt penetration tester |
||
FDL-0401 |
FDL-0431 |
FDL-0501 |
FDL-0601 |
FDL-0631 |
FDL-0701 |
|
Standards |
GB/T5304 |
SH/T0736 |
SH/T0425, T0615 |
T0613, GB/T4501 |
T0613 ,GB/T4501 |
SH/T0600 |
Power supply |
AC 220V ± 10%, 50Hz |
|||||
temperature range |
163 ℃ ± 0.5 ℃ |
5 ~ 50 ℃ |
-10 ℃ ~ + 30 ℃ |
-30 ~ 100 ℃ |
-27 ℃ ~ 25 ℃ |
room temperature ~ -75 ± 1 ℃ |
Temperature Resolution |
± 0.5 ℃ |
± 0.5 ℃ |
± 0.5 ℃ |
1 ℃ |
± 0.5 ℃ |
|
heating power |
2.5kw |
2.4kW |
700W |
|
|
|
beaker effective volume |
|
|
|
|
|
|
relative humidity |
≤85% |
≤85% |
≤85% |
|
≤85% |
|
Power consumption |
|
less than 2.6kW |
less than 1800W |
|
less than 450W |
|
Dimensions |
|
|
|
|
|
|
|
Asphalt rotating thin film oven (82) |
Asphalt rotating thin film oven (85) |
Bitumen wax content analyzer |
Asphalt brittle point tester |
Automatic asphalt brittle point tester |
Asphalt crack point tester |
