LPB8300 Series MiNi Pressure Transmitter

LPB8300 Series MiNi Pressure Transmitter thumbnail-1
LPB8300 Series MiNi Pressure Transmitter photo-1
Negotiable MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
GAOHE
Model Number:
LPB8300 Series
Contact Supplier Request Quote Chat Now
Shanghai Gaohe Imp. & Exp. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai China(mainland)
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name GAOHE
Model Number LPB8300 Series

Specifications

LPB8300 series use the sensor elements with high accuracy, stability and reliability.

      Scope of application

  • Light industry
  • Medical instrumentation
  • Spaceflight machine
  • petroleum chemical industry
  • Process pressure control
  • Hydraulic and air pressure system
  • Internal-combustion engine,refrigeration,air-condition
  • Compressor
  • Foodstuff,sanitation,medical,drink

Technical parameter



Linear:Superior to 0.25%F S

Thermal effect:±0.03%F S/℃

1 year stability:superior to 0.25%F S

Response time:≤10ms

Power supply:24 VDC(or 12~35VDC)

Output:4~20mA

Load(Ω):<(U-12)/0.02A

Proof pressure:150%F S

Burst pressure:300%F S

Compensate Temp: -10~+70℃

Storing Temp: -40~+125℃

Process connection:M20*1.5 male or 1/2NPT male

Mounting position effect:unrestricted

Enclosure Protection:IP65

Wetted parts:304 stainless steel

Diaphragm material:316L stainless steel

Housing material:stainless steel

Electrical connection:DIN 43650 Plug Connector

Weight:about 500g

Power onsume:<0.5W(24VDC)



Connected diagram:

LPB8300 Series MiNi Pressure TransmitterLPB8300 Series MiNi Pressure TransmitterLPB8300 Series MiNi Pressure Transmitter
