LPB8100 Series High Performance Pressure Transmitter

      Scope of application

• Light industry
• Medical instrumentation
• Spaceflight machine
• petroleum chemical industry
• Process pressure control
• Hydraulic and air pressure system
• Internal-combustion engine,refrigeration,air-condition
• Compressor
• Foodstuff,sanitation,medical,drink

Technical parameter

Linear:Superior to 0.25%F S

Thermal effect:0.03%F S/℃

1 year stability:superior to 0.25%F S

Response time:≤10mS

Power supply:24VDC(or 12~35VDC)

Output:4 to 20mA(or 0 to 10 mA,1 to 5V,0 to 10V)

Load(Ω):<(U-12)/0.02A;0 to 1200Ω(for 0 to 10 mA)

Proof pressure:150%F S

Burst pressure:300%F S

Operating Temp: -20~+85℃

Compensated Temp: -10~+70℃

Storing Temp: -40~+125℃

Process connection:M20*1.5 male or 1/2NPT male

Electrical connection:M20*1.5male

Explosion-proof rating:Exia II CT 4;Exd II 6

Wetted parts:304 stainless steel

Diaphragm material:316 stainless steel

Housing material:aluminium

Weight:about 850g

Power consume:<0.5W(24VDC)

Connected diagram:
