Home > Manufacturing & Processing Machinery > Plastic Machinery > Blow Molding Machine > G-1000 High-voltage Fully Automatic High-speed Coiler
G-1000 High-voltage Fully Automatic High-speed Coiler
US$ 15,000 - 18,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Film
Plastic Processed:
PE
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Shutter Paper Interval Cutting MachineUS$ 15,000 - 18,500MOQ: 1 Set -
Capacitance Graded Bushings Winding MachineUS$ 15,000 - 18,500MOQ: 1 Set
-
Half-fold Wrapping MachineUS$ 15,000 - 18,500MOQ: 1 Set
-
PG-500 Parallel High-tension Coil WinderUS$ 15,000 - 18,500MOQ: 1 Set
-
Non-local-discharge Condenser Type Bushing Full-automatic Broadsheet WrappngUS$ 15,000 - 18,500MOQ: 1 Set
Condition
New
Application
Film
Plastic Processed
PE
Blow Moulding Type
Extrusion Blow Moulding
Automatic
Yes
Place of Origin
China
Brand Name
GAOHE
Model Number
GAOHE
Voltage
380VAC,440VAC
Power(W)
22KW
Dimension(L*W*H)
1800x2400x3200
Weight
2000
Certification
CE
Warranty
2
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
High quality film blowing machineEquipped brand electric parts
UDeflecting-correctionpper-driving and Three layers blowing ma
G-1000 high-voltage full automatic high-speed coiler
Performance Characteristics:
Applicable to the high-speed winding of mutual inductor high-voltage trapezoidal wire coils used for voltage transformers and JD(S) QXFseries transformers, with the wire diameter of the electromagnetic wire being<0.56mm GIS.
With the wire coiling speed up to 1000 rpm, the production efficiency is high. With menu type control, after menu input, the tension, the wire winding position and the film dimension are automatically controlled during the whole process of the equipment. Depending on the requirements for insulation width and length if individual layers of the wire coil, the film is automatically cut off according to the programmed requirements. With computerized automatic wire arranging, the wire-arranging arm automatically adjusts the position according to the diameter of the wire coil. With imported electronic tensioner, the tension can be preset in accordance with different wire diameters so that the tension is stable and visible, the wire breakage is minimized and the reliability of the wire coil is improved. After wrapping, the product is stable under high voltage, with little local electric discharge, which is appreciated by manufacturers in the industry. The machine is easy for operation and convenient for maintenance.
Technical parameters:
Max. outside diameter of finished product |
Φ650mm |
|
Inside diameter |
Φ100-300mm |
|
Wire diameter range |
Φ0.1-1.0mm |
|
Wire-arranging feed amount of each turn |
Arbitrary valllue |
|
Wire-coiling width |
450mm |
|
Wire-coiling speed |
0-1000rpm |
|
Wire-coiling direction |
Bi-directional, programmable |
|
Principal axis center height from the ground |
1000mm |
|
Principal axis torque |
1000Nm |
|
Max. weight of wire coil |
200kg |
|
Max. number of layers of wire coil |
300layers |
|
Wire-arranging control precision |
±0.01mm |
|
Counter |
0.0-999999.9 |
|
Alarm shut-down precision |
1 circle |
|
Insulation material thickness |
20-90μm |
|
Insulation material |
||
Insulation width |
50-650mm |
|
Weight per insulation unit |
100kg |
|
Inside diameter |
Φ76mm |
|
Outside diameter |
350mm |
|
Noise grading |
≤65db |
|
Compressed air |
0.4-0.6Mpa |
|
Power supply |
3*380V, 50Hz |
|
