Specifications
H2S monitor/Hydrogen sulfur leak detectorHigh accuracy,advanced sensor
4~20mA current signal
Delivery in time
Best service
NZ03 fixed H2S gas leak detector/Hydrogen sulfur detector
0086 15037127860
Main technical parameters:
Measuring gas | H2S/Hydrogen sulfur |
Measuring range | 0-1000ppm |
Resolution | 1ppm |
Sensor Principle | electrochemical |
Accuracy | ±3%F.S |
Response time | ≤30 s |
Temperature range | -20 - +50°C |
Humidity range | 15% - 95% RH (non-condensing) |
Output signal | International standard 4-20mA signal can be directly access to the plant DCS system(Users can choice) |
Transmission cable | Two-core shielded cable ( three cores shielded cable for combustible gas section:2×1.5mm2,external diameter <10mm |
Transmission Distance | ≤1000m |
Working Voltage | AC220V |
Alarm point | First level alarm point 10ppm two-level alarm point 20ppm (Users can set the alarm point by theirselves) |
Alarm output | Relay Output, Capacity AC 220V 2A |
Display Mode | LED nixie tube display(you can select LCD) |
Dimension | 327mm(L)x 150mm(W)x75mm(H) |
Instrument net weight | 1.5Kg |
Instrument case | Die-casting aluminum |
Service entrance | stainless steel explosion-proof and water-proof connect (Lock diameter 8mm ) |
Mounting means | Wall mount |
Explosion-proof grade | Exd IICT6 ( explosion-proof applications ) ; ExiaIICT4 |
Protection grade | IP66 |
Introduction:
NZ03 wall mounted single gas detector is mainly used in industrial environment. It adopts
advanced electrochemical sensor of high accuracy and good linearity. It's easy to connect with
other instruments and controllers because it has a 4~20mA current signal.The alarm output can
connect with a fan or other alarm device.
It can work in harsh environment and has dust-proof,damp-proof and other advantages. It
widely used in underground pipeline, mine, oil field and other places to rescue the combustible
gas and toxic gas from leakage and protect personal safety and equipment safety effectively.
Gas Selection sheet:
