CE Wood Pellet Making Machine for sale 0086 15838349193
1. Brief Introduction to Wood Pellet Making Machine
Ring die Wood Pellet Making Machine is specially designed for mass industrial production of wood pellets. The raw materials are easy to obtain, like groundnut shell, sawdust, paddy straw, wheat straw, palm husk, rice husks, etc and many other agro and forestry wastes. The final pellets can be used for industrial boilers and large power plants as well as home heating.
2. Remarkable Features of the Wood Pellet Making Machine
1. Main drive adopts high accurate gear drive, with an output of about 20% higher than belt drive.
2. The drive part of the Wood Pellet Making machine including motor optimize, the high quality bearings and oil seals ensure high efficient and steady driving with low noise.
3. The imperative feeder device is adopted, which making the machine operate smoothly as the material like wood sawdust, corn, wheat, and rice straw is very light, so they are needed to be pushed into pelletizing chamber by force.
4. Special design of feed conditioner adopts the frequency-conversion speed regulating control to guarantee wood pellets quality.
5. The ring die is made by international advanced technology, has long service life and ensure smoothly pelletizing and high quality.
6. The international advanced compensation type flexible coupling is of novel and compact structure, safety, low noise and less trouble.
7. Permanent magnet device can remove impurities in the pelletizing process.
3. Operating Instructions of the Wood Pellet Making Machine
1. Have a better understanding of the pellet mill structure and performance, and strictly follow the operation instructions and professional technical personnels’ guidance.
2. Pay attention to regular maintenance and repair so as to extend the machine service life.
3. The operator should stay at the working area while pellet mill is under running condition.
4. It’s wise to choose appropriate pellet mill according to different raw materials and capacity requirements.
4. The Technical Parameter of the Wood Pellet Making Machine
Model |
Capacity T/H |
Main Power |
feeder power |
Conditioner power |
Ring die Diameter |
pellets size(mm) |
Dimension (mm) |
MZLH320 |
0.2--0.4 |
37 KW |
0.55kw |
2.2kw |
φ320mm |
φ6.0,φ8.0,φ10.0,φ12.0 |
2100*800*1300 |
MZLH350 |
0.4--0.6 |
55 KW |
0.55kw |
2.2kw |
φ350mm |
2200*900*1500 |
|
MZLH420 |
1-1.2 |
90 KW |
1.5kw |
5.5kw |
φ420mm |
3200*1100*1700 |
|
MZLH508 |
1.5--2.0 |
132 KW |
1.5kw |
5.5kw |
φ508mm |
3200*1300*1900 |
|
MZLH558 |
2.5-3.5 |
185KW |
1.5kw |
5.5kw |
φ558mm |
3500*1500*2800 |
5. The finishes pellets of the Wood Making Pellet Machine
Size range of making wood pellets - 6mm, 8mm, 10mm,12mm
Quality guarantee - 2 years guarantee for main body.
6. The Process of complete wood pellet line(As your own need)
Our complete wood pellet plant has a compact structure, low energy consumption and is highly efficient. Every machine in the wood pellet plant can be designed and manufactured according to customers’ requirements. Professional technical guidance of installing the machinery is also available.The whole process of wood pellet line can be highly automatically controlled. It includes the below processes.
Wood crusher-sawdust dryer-pellet making machine-pellet packing.
Crushing process-Drying process-Pelletizing process-Cooling process-Packing process
7. The picture of the Wood Pellet Mking Machine:
