Geo Textiles

Name: Geo Textiles
Brand: pretty lion
SKU: 106160289
Availability: InStock

US$ 0.2 - 3 MOQ: 1 Square Meter

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

pretty lion

Model Number:

100gsm-1500gsm

Taian Pretty Lion Light Industrial Products Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB qingdao or CNF/CIF

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name pretty lion

Model Number 100gsm-1500gsm

Geotextile Type Non-Woven Geotextiles

NONWOVEN geo textiles

Nonwoven geotextile technical datas

Item Unit weight,g/m²	100	150	200	250	300	350	400	450	500	600	800
Unit weight tolerance %	-8	-8	-8	-8	-7	-7	-7	-7	-6	-6	-6
Thickness ≥mm	0.9	1.3	1.7	2.1	2.4	2.7	3.0	3.3	3.6	4.1	5.0
MD/CD break strength ≥kN/m	2.5	4.5	6.5	8.0	9.5	11.0	12.5	14.0	16.0	19.0	25.0
CBR burst strength ≥kN	0.3	0.6	0.9	1.2	1.5	1.8	2.1	2.4	2.7	3.2	4.0
MD/CD Tearing strength ≥kN	0.08	0.12	0.16	0.20	0.24	0.28	0.33	0.38	0.42	0.46	0.60
Width tolerance%	-0.5
MD/CD Elongation %	25-100
EOS O₉₀, mm	0.07-0.2
Vertical permeability coefficient, cm/s	Kx(10^-1-10^-3)K=1.0-9.9

Continuous filament non-woven geotextile technical data

No	indexs specs item	100	150	200	250	300	350	400	450	500	600	800
1	Unit weight tolerance %	-6
2	Thickness ≥mm	0.8	1.2	1.6	1.9	2.2	2.5	2.8	3.1	3.4	4.2	5.5
3	MD/CD break strength ≥kN/m	45	75	10.0	12.5	15.0	17.5	20.5	22.5	25.0	30.0	40.0
4	MD/CD Elongation %	40-80
5	CBR burst strength ≥kN	0.8	1.4	1.8	2.2	2.6	3.0	3.5	4.0	4.7	5.5	7.0
6	MD/CD Tearing strength ≥kN	0.14	0.21	0.28	0.35	0.43	0.49	0.56	0.63	0.70	0.82	1.10
7	EOS O₉₀, mm	0.07-0.2
8	Vertical permeability coefficient,cm/s	Kx(10^-1-10^-3),and K=1.0-9.9
9	Width tolerance%	-0.5
