Sm481 Mounter Pick and Place Machine
Main product: SMT machine, SMT shooter, chip mounter, SMT equipment, SMT placement machine, SMT mounting machine, electronic equipment, PCB machine and place machine, SMT assembly, SMT/SMD equipment, SMD equipment
Pick & Place Machine -SM481 Flexible Chipshooter
Easy to use software allows users to quckly learn the machine and get the most from it. Standard component library has more than 1800 shapes and the polygonic algorithm automatically detects component outlines on difficult components.
Features:
Built in vacuum pump making air consumption just 50Nl/min! ! ! !
Easily Identifieable Feeders
Adaptive Pick Up
Front and back operation as standard
Large PCB Size of 460mm X 400mm
01005 component recognition as standard
120 X 8mm Feeder Capacity
Placement Rate: 39'000cph optimum
Placement Accuracy: ± 50µ @3σ /Chip
± 30µ @3σ /QFP
Component Range: 01005~16mm² By flying vision
Optional Camera available for devices up to 42mm²
Max Height = 10mm, (15mm Optional)
PCB Size: 460mm X 400mm
PCB Thickness: 0.38 ~ 4.2mm
Feeder Capacity: 120 X 8mm
Options:
Fixed Cameras for larger devices
15mm Component height optional (Factory order only)
Intelligent Feeder and Parts system
Feeder Docking Carts
Flux Dipping Feeder
