Samsung chip shooter SM471/LED CHIP MOUNTER DECAN
LED mounter sm481/SMT MOUNTER 482S/Samsung chip shooter SM471
Features:
0201 component recognition as standard
120 X 8mm Feeder Capacity
High Accuracy ± 30µ @3σ /Chip
Small Footprint of just 1650mm X 1690mm X 1535mm
5kVA Max Power
PCB Size: 510mm X 460mm
PCB Thickness: 0.38 ~ 4.2mm
Feeder Capacity: 120 X 8mm
Placement Rate: 2'000cph(9850IPC) 1608Chips
Placement Accuracy: ± 50µ @3σ /Chip
SMT equipment, PCB assembly machine, SMT mounting, sm482, Samsung chip mounter, Samsung chip shooter.
Component Range: 0201~14mm² By flying vision
Max Height = 12mm
Options:
Board Size 510mm X 250mm (Dual Lane)
Board Size 610mm X 250mm (Dual Lane)
Product Description
Pick and place machine, chip mounter, sm481 chip mounter, chip shooter sm471, SMT machine,
Pick & Place Machine - Samsung SM481 High Speed Placer
Highly reliable SM481 is the 6th generation of Full Vision mounter from Samsung Techwin and 4th Generation Dual Gantry System developed.
Cost of ownership is extremely low due to the simple yet reliable Dual Gantry X/Y/Z structure.
Easy to use software allows users to quckly learn the machine and get the most from it. Standard component library has more than 1800 shapes and the polygonic algorithm automatically detects component outlines on difficult components.
