Eta LED Semi-automatic Printer

Eta LED Semi-automatic Printer thumbnail-1
Eta LED Semi-automatic Printer thumbnail-2
Eta LED Semi-automatic Printer thumbnail-3
Eta LED Semi-automatic Printer thumbnail-4
Eta LED Semi-automatic Printer thumbnail-5
Eta LED Semi-automatic Printer thumbnail-6
Eta LED Semi-automatic Printer photo-1
Eta LED Semi-automatic Printer photo-2
Eta LED Semi-automatic Printer photo-3
Eta LED Semi-automatic Printer photo-4
Eta LED Semi-automatic Printer photo-5
Eta LED Semi-automatic Printer photo-6
US$ 50 - 5,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ETA
Model Number:
smt automatic Printer,led automatic stencil Printer
Contact Supplier Request Quote Chat Now
Shenzhen ETA Electronic Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
HONGKONG
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ETA
Model Number smt automatic Printer,led automatic stencil Printer

smt stencil printer, smt screen printer, smt SEMI-automatic Printer,led automatic stencil Printer,led PCB printer

SMT Screen automatic solder paste stencil Printer

eta LED Semi-automatic Printer

eta LED Semi-automatic Printer

 Configuration:

1.         Suspended print head with squeegee pressure automatic adjustment by direct-connected motor

a)         Programmable automatic pressure adjustment system ensures accurate pressure control.

b)        Pressures of front and rear squeegees are separately adjusted, to compensate pressure imbalance caused by fatigue deformation of squeegee to prevent from different printing quality in front and rear.

  1. 2.         Standard stainless steel squeegee, unique design to improve the lifespan of squeegee blade.
  2. 3.         Vision alignment system.
  3. 4.         Table X/Y/θ automatic calibration system.
  4. 5.         PCB clamping and support system:

a)         Magnetic pins

b)        PCB flexible side clamping system to ensure no bending and deformation during PCB clamping

c)         Automatic adjustment lifting platform.

d)        Flexible automatic pin(optional)

eta LED Semi-automatic Printer

eta LED Semi-automatic Printer

      i.    General Introduction:

1.          Product Functions:

Cp5 a high precision automatic solder paste screen printer designed for high precision screen printing or stencil printing in SMT industry.





eta LED Semi-automatic Printer

            Items



               Parameter

Repeat Position Accuracy

±0.01mm(test data and method can be provided)

Printing Accuracy

±0.025mm(test data and method can be provided)

Cycle Time

<9s (Excluding Printing & Cleaning)

Products Changeover

<5Min

Screen Stencil Size/Min

470mm X 370mm

Screen Stencil Size/Max

737mm X 737mm

Screen Stencil Size/Thickness

20mm ~ 40mm

PCB Size/Min

50X50mm

PCB Size/Max

400X340mm

PCB Thickness

0.6~6mm

PCB Warpage Ratio

<1%(Based on diagonal length)

Bottom of Board Size

10mm

Edge of Board Size

3mm

Transport Height

900±40mm

Transport Direction

Left-Right; Right-Left; Left-Left; Right-Right

Transport Speed

100-1500mm/sec Programmable

Board Location

Support System

Magnetic pin/Side support block/Flexible automatic pin(optional)

Clamping System

Elastic side clamping/ Elastic Z-direction tabletting (optional, but not suggested)

Print head

Direct-connected motor control of the squeegee pressure

Squeegee Speed

10~150mm/sec Programmable





Stencil Separation Speed

0.01~10mm/sec Programmable

Cleaning Method

Dry-type, wet-type ( Programmable combination of the two cleaning methods)

Table Adjustment Range

X: ±4mm;Y:±6mm;θ:±2°

Type of Image Fiducial Mark

Standard geometry shape of fiducial mark, bonding pad / stencil hole

Camera System

Single digital camera with upward/downward vision system

Air Pressure

4~6Kg/cm2

Air Consumption

Approx. 0.07m3 /min

Control Method

PC Control

Power Supply

AC:220±10%,50/60HZ 1Φ 1.5KW

Machine Dimensions

1220mm(L) x 1410mm(W) x 1550(H)mm (excluding the height of indicating lighthouse)

Weight

Approx:1000Kg

Operation Temperature

-20°C ~ +45°C

Operation Humidity

30%~60%
