Single belt type conveyor roller assembly line, Electronics conveyor roller assembly line
Specifications
Tech-specifications
the whole line is made /connected one by one section .
Normal Dimensions : 2.5m*0.9m *1.6m (L*W*H) can made by your requirements.
1. 2.4 meters/section, each section can be configured for 3-4 station, motor Imported from Tai Wan 60 w with 1:50 tooth transmission system, electronic stepless speed regulation
2.The skeletons using 40 x 40 mm stainless steel materials, table plate use δ2 iron plate bending forming, beautiful and durable
3.Speed range :0.3 - 3m /min can be regulated ( automatic running)
4.PCB size : 50 -300mm available
5.. The chain rail choose ETA special aluminum 51 * 56
6.Use nylon chain transmission, high precision, smooth transmission
7.Each section Equipped with 3 sets of A4 plastic document fixtures for process procedure guide
8.One working place one power sockets
9. With W170 parts box connected to the move rail , convenient to insertion and save Labor
10..Each section has two 30W tube lights ,, independent switch
11.Power supply 1φ 220VAC 50Hz
12.Steel surface :computer white paint .
CFL insertion line,
Automatic PCB & CFL insertion line for dip,
PCB insertion line for dip production line, Dip insertion line,
Insertion line : insertion components on the board ,insert components on pcb,
dip line pcb dip assembly line insertion line with pcb width adjustble
Technical specificatin:
1. 2.4 meters/section, each section can be configured for 3-4 station, motor Imported from Tai Wan 60 w with 1:50 tooth transmission system, electronic stepless speed regulation
2.The skeletons using 40 x 40 mm stainless steel materials, table plate use δ2 iron plate bending forming, beautiful and durable
3.Speed range :0.3 - 3m /min can be regulated ( automatic running)
4.PCB size : 50 -300mm available
5.. The chain rail choose ETA special aluminum 51 * 56
6.Use nylon chain transmission, high precision, smooth transmission
7.Each section Equipped with 3 sets of A4 plastic document fixtures for process procedure guide
8.One working place one power sockets
9. With W170 parts box connected to the move rail , convenient to insertion and save Labor
10..Each section has two 30W tube lights ,, independent switch
11.Power supply 1φ 220VAC 50Hz
12.Steel surface :computer white paint .
1.Type: single belt ,opposite seats ( side seats ) (PDX)
2.Workers' seat: ( length of line accord to customer requirments )
3.Length for seat: 2000mm, total length 20m. (The length can accord to customer's
requirement. )
4.Total width for production line: belt width 400mm,working table width 400mm
5.Total height for production line: about 2000mm, working surface level, 720-750mm(adjustable).
6.Speed: 0.3-3m/min ( adjustable).
Packing: Wooden case.
