New Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter With Receiver

New Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter With Receiver photo-1
New Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter With Receiver photo-2
New Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter With Receiver photo-3
New Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter With Receiver photo-4
New Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter With Receiver photo-5
New Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter With Receiver photo-6
US$ 4.48 - 4.48 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Brand Name:
vizgiz
Model Number:
1243
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
HongKong
Delivery Detail:
Delivery time depends on order quantity.
Brand Name vizgiz
Model Number 1243
Place of Origin Guangdong, China

Features:
100% new and high quality
Three output working modes for choosing
Safe and flexible for operation and install
Widely use in house, mall, electromobile, cars, motorcycle anti-theft alarm system or other control systems
Specified as preferred components in remote control garage, roller curtain, door locks, remote sensing, telemetry, industrial control and wireless security alarm industry

Specifications:
Size: 35*32*17mm
Operating voltage: DC 12V
Operating Current: 6mA
Operating frequency: 433MHz
Operating temperature: -40 to + 80
Receiver sensitivity: -105dbm
Output voltage: DC
Output Current: 10A
Code: Learning code. (Jog/ Non-Locked, Inter-lock/ locked, Auto-lock / Auto-Locked)

Output working way:
Jog /Non-locked: Press a button is working/ on and loosen your finger on the same button is stop/ off. (A channel change needs a remote control button)
Auto-lock: Press one button for one time is working/ on and press the same button is stop/ off. (A channel change needs a remote control button)
Inter-lock / locked: Press a button is working/ on and press another button is stop/ off. (A channel change needs 2 remote control buttons)

Learning and removing method:
1. Learning method: Press the learning code for 3 seconds. The indicator will be off, and then loosen your finger, press any button of the remote control to transmit signal, the indicator flash 3 times and then normally on which means you learn it successfully.
2. Remove/clean method: Press the learning button about 8 seconds, the indicator will be from being off to on all the time, it means the information that you keep have been removed successfully. New Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter with ReceiverNew Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter with ReceiverNew Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter with ReceiverNew Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter with ReceiverNew Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter with ReceiverNew Universal Wireless Remote Control Controller Switch 1 Single Channel DC12V 10A 433MHz Telecomando Transmitter with Receiver
