Dongfeng Sewage Suction Truck

Name: Dongfeng Sewage Suction Truck
Brand: DALI
SKU: 106103409
Availability: InStock

US$ 20,000 - 30,000 MOQ: 1 Set

Key Specifications

Condition:

New

Drive Wheel:

4x2

Type:

Rear Loader

Hubei Haotian Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Drive Wheel 4x2

Type Rear Loader

Transmission Type Manual

Emission Standard Euro 3

Volume 10001 - 15000L

Fuel Type Diesel

Engine Capacity 6618

Size 9890*2490*3500

Gross Vehicle Weight 25000

Place of Origin Hubei, China

Brand Name DALI

Model Number DLQ5060

Specifications

Dongfeng Sewage suction truck
Drive configuration:4*2;Engine power:175hp
Preferential prices, welcome to choose and buy!

Dongfeng Sewage suction truck

MAIN SPEC.
ITEM	MODEL&SPEC.	MANURACTURER
SPECIAL VEHICLE	CLQ1253P7K2L7T1E	Hubei DALI Special Purpose Vehicle Co., Ltd
CHASSIS	CA1253P7K2L7T1E	FAW Group
ENGINE	CA6DE3-22E3	FAW Group

CHASSIS TECHNIQUE PARAMETERS:
ITEM	MODEL&SPEC.	ITEM	MODEL&SPEC.
Drive System	6*4	Emission Standard	GB3847-2005,GB17691-2005 CN3
Displacement (ml)/Power(kw)	6618/162	Tyre & Spare Tyre Spec	9.00-20
Gross /Rated / Kerb Mass(kg)	25000/12500/12305	No. of Leaf Springs	4/10
Dimension(LWH)(mm)	989024903500	F/R Suspension(mm)	1375/2440
Wheelbase/Axis No.(mm)	4725+1350 /3	Approach /Departure Angle(°)	20/9
F/R- Gearcase		F/R Truck(wheel base) (mm)	1914/1847
Cab		Clutch
Steering-Gears		Brake System
Gearbox

VEHICLE MODIFCATION TECHNIQUE INFORMATION
ITEM	MODEL&SPEC.	ITEM	MODEL&SPEC.
Cubage(m3)	13-16	Max Vertical Suction	≥8
Material	Q235 Carbon Steel	Absolute Pressure	8500Pa
Figure	Round	Rotate Speed	500
Dimension(LWH)(mm)	480020122012	Flow rate(Theory)	98L/S
Vacuum Pump	China	Shaft Power	5.5kw
Manufacturer Qualification	Measure up (CN standard)	Air in-outlet calibers	50mm
Painting	Metallic Paint	Container Filling Time	5s
Spare Parts & Accessories	Maintenance Manual, Services Stations List, Introduction, Tools	Container Emptying Time	4s
Configure	Original FAW 3 unit Axles chassis cab over with line, super power of suction vacuum pump, seamless die casted shell cover, thickness designing for container which with high ability of pressure-resistance, double hydraulic jack system, more strength then Cesspit Emptier.
Applied Function	Main used to collect sewage sludge and feces by environment section, especially for suck and empty suck contaminated water out of hollows such as cesspools andsewage tanks and carry it to a disposal point. Approach for emptying with pressure outlet and flow automatically. Gully emptier works efficiently, automatic suction and automatic outlet, especially it easy for operating. suitable for townish environment section to equipped.
