6061 6063 t6 t5 rectangular tube aluminium price per kg in shanghai
- 150 Ton / Tons per Month
- shanghai-6061 6063 t6 t5 rectangular tube aluminium price per kg
- T/T L/C D/P D/A Credit Card PayPal
- 6061 6063 T6 T5 aluminium alloy led tube light aluminium price per kg in shanghai
- 6063 T5 T6 aluminium pipe for clothing hanging for military vehicles for sale aluminium price per kg
- 6063 T5 T6 aluminum flexible duct pipe for military vehicles for sale aluminium price per kg
- extruded aluminium tube with ISO quality guarantee from Shanghai Jiayun
- customized aluminium tubes and pipes, aluminium lightweight pipe made in china shanghai
- 6061 6063 T6 T5 lacquer aluminium collapsible tube for stair edge protection aluminium price per kg in shanghai
Product Details
Place of Origin: | Shanghai, China | Grade: | Other, 6000 Series, 6000series | Shape: | Round |
Surface Treatment: | Other, 6061 6063 t6 t5 rectangular tube aluminium price per kg | Outer Diameter: | <250mm | Length: | <6000mm |
Thickness: | >0.8mm | Usage: | 6061 6063 t6 t5 rectangular tube aluminium price per kg | Hardness: | 8-10HW |
Alloy Or Not: | Is Alloy | Temper: | T3 - T8 | Al (Min): | 98% |
Wall Thickness: | >0.8mm | Model Number: | 6063,6061,6060,6005 | Brand Name: | JY-6061 6063 t6 t5 rectangular tube aluminium price per kg |
Packaging Details
6061 6063 t6 t5 rectangular tube aluminium price per kg:wrapped with Ep film; external pack:rolled by kraft paper or packaged by plastic film. other request like paper box, carton, wooden box, iron pallet, etc is ok, we also can print your logo, address, products' specification on the paper box, but you have to charge extra fee.
Product Description
6061 6063 t6 t5 rectangular tube aluminium price per kg description
1.Typical chemical composition of most commonly used material:
Material | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
6005 | 0.6~0.9 | 0.35 | 0.1 | 0.1 | 0.4~0.6 | 0.1 | 0.1 | 0.1 | 0.15 | rest |
6061 | 0.4~0.8 | 0.7 | 0.15~0.4 | 0.15 | 0.8~1.2 | 0.04~0.35 | 0.25 | 0.15 | 0.15 | rest |
6063 | 0.2~0.6 | 0.35 | 0.1 | 0.1 | 0.45~0.9 | 0.1 | 0.1 | 0.1 | 0.15 | rest |
2. 6061 6063 t6 t5 rectangular tube aluminium price per kg properties
Alloy | Temper | Tensile | Yield strength σ0.2/Mpa | Elongation | Hardness |
6063 | T5 | ≥160 | ≥110 | ≥8% | ≥60 |
T6 | ≥205 | ≥180 | ≥8% | ≥70 |
3. 6061 6063 t6 t5 rectangular tube aluminium price per kg pecifications
1. Material: alloy 6005 6060 6061 6063
2. Temper: T5, T6
3. Surface treatment: anodizing, powder coating, wooden grain, sand blasting etc.
4. Color: any color is available, just bring us your color sample
5. Style and size: customized
6. Deep processing: extrude, precious cut, punch, drill, tap, mill, rivet, weld etc.
7. Extruding machine: 600-2500tons
4.Our production lines
Production lines | Name | Qty | Max product length |
Extruding lines | 600 ton extruder | 5 | |
800 ton extruder | 2 | ||
1000 ton extruder | 1 | ||
1250 ton extruder | 1 | ||
1800 ton extruder | 1 | ||
2500 ton extruder | 1 | ||
Surface treatment lines | Anodizing | 1 | ≤6.5 m |
Powder coating | 2 | ≤13 m | |
Electrophoresis | 1 | ≤6.5 m | |
Wooden transfer | 1 | ≤6.5 m | |
Hot insulation cold bridge | 1 | ≤6.5 m | |
Deep processing lines | Cutting machines | 3 | |
Punching machine | 5 | ||
Milling machine | 3 | ||
CNC machine | 3 | ||
Polishing machine | 1 | ||
Tapping machine | 5 | ||
Riveting machine | 1 |
Our factory
Our Guests:
our services
Cost Competitive
We can control all the manufacture process from extruding to machining by ourselves, which is why we can reduce the product cost comparing to our competitors.
Quality Guarantee
We will inspect the whole process from material, production, finished profiles.if any quality problems of our products, we promise to replace the defective ones in the next shipment.
OEM Capability
We make various kinds finished aluminum extrusions and further processed product from machined piece, we respect client's designs and work to perfect product.
High quality products
Price is important, but quality counts for much more, so we dedicated in superior quality. In this way, our products have been sold to Europe, North America, Japan, New Zealand and other countries and enjoy a good reputation from overseas customers.
any inquiry will be replied within 8 hours, hope fully to be your trustworthy supplier in China
Company Profile
Shanghai Jiayun Aluminium Co., Ltd. Locates at Fengxian district of Shanghai. It is a modern company which is a collection of R & D, production and sales of aluminium and also its deep processing products.
Jiayun adopts the world-class production lines brought from Japan, Taiwan and so on. It gathers complete technical processes such as mould making, casting, extruding, anodizing, electrophoresis and powder coating. Now the company specifically develops aluminium deep processing like precision cutting, milling, punching, drilling, tapping and also the assembly of the aluminium products, etc.
Jiayun also adopts the quality management system ISO9001:2008 and the environmental management system ISO14001:2004. It develops aluminium extruding in sync with aluminium deep processing.
With 10 years of R&D, Jiayun products have reached to one hundred thousand varieties, which are widely used in technology, machinery, electronics, appliances, automotive, construction and other industries.
It supplies mature deep processing products around the world such as assembly barrier, heat sink, display equipment, motor shell, aluminium furniture, aluminium ladders, LED lamps & its assembly accessories, solar panel frames and aluminium brackets accessories, etc.
Jiayun has always been carrying out the belief of "quality first, sincerity first" in face of all customers around the world with its first-class service.
