customized aluminium tubes and pipes, aluminium lightweight pipe made in china shanghai
1.Typical chemical composition of most commonly used material:
| Material | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Impurity | Al |
| 6005 | 0.6~0.9 | 0.35 | 0.1 | 0.1 | 0.4~0.6 | 0.1 | 0.1 | 0.1 | 0.15 | rest |
| 6061 | 0.4~0.8 | 0.7 | 0.15~0.4 | 0.15 | 0.8~1.2 | 0.04~0.35 | 0.25 | 0.15 | 0.15 | rest |
| 6063 | 0.2~0.6 | 0.35 | 0.1 | 0.1 | 0.45~0.9 | 0.1 | 0.1 | 0.1 | 0.15 | rest |
2.6063 aluminium profile properties
| Alloy | Temper | Tensile |
Yield strength σ0.2/Mpa |
Elongation |
Hardness |
| 6063 | T5 | ≥160 | ≥110 | ≥8% | ≥60 |
| T6 | ≥205 | ≥180 | ≥8% | ≥70 |
3. Frequently Asked Question (FAQ)
1. Material: alloy 6005 6060 6061 6063
2. Temper: T5, T6
3. Surface treatment: anodizing, powder coating, wooden grain, sand blasting etc.
4. Color: any color is available, just bring us your color sample or tell us your colour number
5. Style and size: customized
6. Deep processing: extrude, precious cut, punch, drill, tap, mill, rivet, weld etc.
7. Extruding machine: 600-2500tons
4.Our production lines
| Production lines | Name | Qty |
Max product length |
| Extruding lines |
600 ton extruder | 5 |
|
| 800 ton extruder | 2 | ||
| 1000 ton extruder | 1 | ||
| 1250 ton extruder | 1 | ||
| 1800 ton extruder | 1 | ||
| 2500 ton extruder | 1 | ||
| Surface treatment lines | Anodizing | 1 | ≤6.5 m |
| Powder coating | 2 | ≤13 m | |
| Electrophoresis | 1 | ≤6.5 m | |
| Wooden transfer | 1 | ≤6.5 m | |
| Hot insulation cold bridge | 1 | ≤6.5 m | |
| Deep processing lines | Cutting machines | 3 | |
| Punching machine | 5 | ||
| Milling machine | 3 | ||
| CNC machine | 3 | ||
| Polishing machine | 1 | ||
| Tapping machine | 5 | ||
| Riveting machine | 1 |
aluminium lightweight pipe show
Production lines & Precesion equipments:
Packing & Certification:
Usually,Inner packed with plastic or EP film,Outer packed with Kraft Paper,Or as to the customers.
1>. For short products, usually we packed each with EP films,then with paper boxes outside.
2>.For long products, usually inner with EP films,then with PE films,then with paper boxes outside.
Certification:
Jiayun also adopts the quality management system ISO9001:2008 and the environmental management
system ISO14001:2004.
aluminium lightweight pipe services
Cost Competitive
We can control all the manufacture process from extruding to machining by ourselves, which is why we can
reduce the product cost comparing to our competitors.
Quality Guarantee
We will inspect the whole process from material, production, finished profiles.if any quality problems of our
products, we promise to replace the defective ones in the next shipment.
OEM Capability
We make various kinds finished aluminum extrusions and further processed product from machined piece,
we respect client's designs and work to perfect product.
High quality products
Price is important, but quality counts for much more, so we dedicated in superior quality. In this way, our
products have been sold to Europe, North America, Japan, New Zealand and other countries and enjoy
a good reputation from overseas customers.
More information?
welcome go to our website https://img13.fr-trading.com/
Or click here to contact to me
