15 Solar Collector SKI-CA From SKI SOLAR

15 Solar Collector SKI-CA From SKI SOLAR thumbnail-1
15 Solar Collector SKI-CA From SKI SOLAR photo-1
US$ 189 - 249 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
SKI SOLAR
Model Number:
SKI-CA
Contact Supplier Request Quote Chat Now
Changzhou SKI Solar Energy Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name SKI SOLAR
Model Number SKI-CA
Type Manifold Collector
Application Other
Pipe Material Copper

Specifications

We are a professional solar water heater manufacturer with ISO and CE certificate in Changzhou, China.

Model: SKI-CA   (Pressurized Solar Heat Pipe Collectors)

1) Heat Pipe     Diameter:  Φ 58mm    Length:  1,800mm

2) Header Pipe Material :  Copper

3) Frame Material:  Aluminium Alloy    Thickness: 2.5mm

4) Manifold Casing Material:  Aluminum Alloy  Thickness: 2mm

5) Manifold Pipe:   Copper     Diameter: 35mm

6) Rubber Seals and Rings :  UV Stabilized High Temperature Silicon Rubber

7) Insulation:    Rock Wool      Thickness: 110mm ;    Density : 80kg/m³

8) Collector Mounting: Flat Roof/Inclined Roof      from 18 degree to 45 degree

9) Collector Support:  Aluminium Alloy   Thickness:  2.5mm       (optional)

10) Inlet/Outlet:   3/4 Inch

11) Packing:   Export Carton

12) Working Pressure: 6 Bar (0.6Mpa)       Test Pressure: 10 bar (1.0Mpa)

13) Working temperature :  -40 degree celsius to 220 degree celsius

14) Permissible wind: 30m/s

15) Snow load: thickness  30cm



Advantage:



1)Delivery time: 15 days after receiving advance payment.         Payment term: T/T , L/C at sight
2)  OEM / ODM is available
3)  Guarantee: 1% of spare parts are free( vacuume tube & plastic ring).   3 years warranty period.
4)  Can produce product as customers special requirements
5)  MOQ: 1 SET  for samples,one container for order.

6)  Loading port: ShangHai

7)  English installation instructions.

Low price, high quality!
