CATV EDFA Optical Amplifier Module

CATV EDFA Optical Amplifier Module thumbnail-1
CATV EDFA Optical Amplifier Module thumbnail-2
CATV EDFA Optical Amplifier Module thumbnail-3
CATV EDFA Optical Amplifier Module photo-1
CATV EDFA Optical Amplifier Module photo-2
CATV EDFA Optical Amplifier Module photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
B&A
Model Number:
M3121
Contact Supplier Request Quote Chat Now
Shanghai B&A Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name B&A
Model Number M3121



Product Description

  CATV EDFA Optical Amplifier Module

CATV EDFA Optical Amplifier ModuleCATV EDFA Optical Amplifier ModuleCATV EDFA Optical Amplifier Module

Optical Characteristics



Parameter

Symbol

Min

Typ

Max

Unit

wavelength

λc

1530

1550

1562

nm

Output power(1)

Po

13

------

22

dBm

Input power

Pi

-3

------

+10

dBm

Gain

G

------

20

------

dB

Noise Figure(2)

NF

------

4.5

-----

dB

Output power stability

ΔPo

-----

±0.05

±0.1

dB

Return loss

RL

-------

-------

-45

dB

Polarization dependent gain

PDG

------

-------

0.3

dB

Polarization mode dispersion

PMD

------

-------

0.5

ps



(1): 2 output ports is available



(2): Test at  0dBm input



Electric Characteristics



Parameter

Symbol

Min

Typ

Max

Unit

voltage

Vps

3.0/4.5

3.2/5.0

3.5/5.5

VAC

consumption

P

-----

----

10

W



consumption is up to the output power and environment temperature



Environmental Characteristics



Parameter

Symbol

Min

Typ

Max

Unit

Operating temperature

Tw

-5

-----

60

℃

Storage temperature

Ts

-40

-----

80

℃

Humidity

------

10

------

85

%



(3):Non-condensing

Order information



Product

Mechanical

Application

Input power

Output power1

Output

Ports

Voltage

Interface

M:module

31:dimension

90×70×15mm

2:fiber amplify

1:

-3~+10

dBm



9:other

13:13dBm

…

22:22dBm

1.:1 port

2: 2 ports

7:5VDC

8:3.3VDC

1: SC/UPC

2: SC/APC

3: FC/UPC

4: FC/APC

5: LC/UPC

6: LC/APC
Size

  M3121:90×70×15mm



Certifications

 CATV EDFA Optical Amplifier Module
