DWDM Optical Amplifier EDFA Module

Name: DWDM Optical Amplifier EDFA Module
Brand: B&A
Price: Negotiable

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Product Details

Place of Origin:

Shanghai, China

Brand Name:

B&A

Model Number:

M3121

DWDM Optical Amplifier EDFA Module

Optical Characteristics

Parameter	Symbol	Min	Typ	Max	Unit
wavelength	λc	1530	1550	1562	nm
Output power⁽¹⁾	Po	13	------	22	dBm
Input power	Pi	-3	------	+10	dBm
Gain	G	------	20	------	dB
Noise Figure⁽²⁾	NF	------	4.5	-----	dB
Output power stability	ΔPo	-----	±0.05	±0.1	dB
Return loss	RL	-------	-------	-45	dB
Polarization dependent gain	PDG	------	-------	0.3	dB
Polarization mode dispersion	PMD	------	-------	0.5	ps

(1): 2 output ports is available

(2): Test at 0dBm input

Electric Characteristics

consumption is up to the output power and environment temperature

Environmental Characteristics

(3):Non-condensing

Size

M3121:90×70×15mm

Packaging & Shipping

Packing Details: Standard export package or customized package

Delivery Details: 5-10days
