1550nm 13~24dBm Optical Amplifier EDFA Module

1550nm 13~24dBm Optical Amplifier EDFA Module thumbnail-1
1550nm 13~24dBm Optical Amplifier EDFA Module thumbnail-2
1550nm 13~24dBm Optical Amplifier EDFA Module thumbnail-3
1550nm 13~24dBm Optical Amplifier EDFA Module thumbnail-4
1550nm 13~24dBm Optical Amplifier EDFA Module thumbnail-5
1550nm 13~24dBm Optical Amplifier EDFA Module photo-1
1550nm 13~24dBm Optical Amplifier EDFA Module photo-2
1550nm 13~24dBm Optical Amplifier EDFA Module photo-3
1550nm 13~24dBm Optical Amplifier EDFA Module photo-4
1550nm 13~24dBm Optical Amplifier EDFA Module photo-5
US$ 100 - 3,000 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
B&A
Model Number:
M8121
Contact Supplier Request Quote Chat Now
Shanghai B&A Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name B&A
Model Number M8121



Product Description

 1550nm 13~24dBm Optical amplifier EDFA Module1550nm 13~24dBm Optical amplifier EDFA Module



1550nm 13~24dBm Optical amplifier EDFA Module



Optical Characteristics

Parameter

Symbol

Min

Typ

Max

Unit

Wavelength

λc

1530

1550

1562

nm

Output power(1)

Po

13

------

24

dBm

Input power

Pi

-3

------

+10

dBm

Gain

G

------

20

------

dB

Noise Figure(2)

NF

------

4.5

-----

dB

Output Power stability

ΔPo

-----

±0.05

±0.1

dB

Return Loss

RL

-------

-------

-45

dB

PDG

PDG

------

-------

0.3

dB

PDM

PMD

------

-------

0.5

ps

(1):Output power and dual output is optional.

(2):Test at 0dBm input



Electric Characteristics

Parameter

Symbol

Min

Typ

Max

Unit

Power supply

Vps

3.0/4.5

3.2/5.0

3.5/5.5

VAC

Consumption

P

-----

----

20

W

Actual consumption depend on the output power and environment temperature

Environmental Characteristics

Parameter

Symbol

Min

Typ

Max

Unit

Operating temperature

Tw

-5

-----

60

℃

Storage temperature

Ts

-40

-----

80

℃

Humidity

------

10

------

85

%

(3):Non-condensing



Size

M8121:164×85×18mm

Packaging & Shipping



Packing Details: Standard export package or customized package

Delivery Details: 5-10days
