Specifications
1.Certified ISO90012.Nice after-sales service
3.Strong technology support
4.Size can be customized
5.Warranty: 1 year
Vacuum resistance evaporation coating machine/ Aluminum vacuum metallization machine/Vacuum machine CCZK-1100
Decorative vacuum coating equipment is evaporation-coated device in a vacuum chamber using electrical resistance heating, will close in the resistance wire on the metal wire vaporization melting, vaporization of the metal elements deposited on the substrate, but was Smooth high reflectivity of the coating to the surface of decorative items landscaping purposes.
Machinable materials include: ABS, PS, PP, PC, PVC
Coating color: Silver, black, golden, yellow, red, green and other rainbow color(sio2)
The company can design all based on user requirements specification models of Vacuum Coaters. Vacuum units and electric control system can be designed according to user requirements configuration.
model |
CCZK -700 |
DCCZK-900 |
CCZK -1100 |
CCZK -1250 |
CCZK-1400 |
Vacuum chamber structure |
700×H900mm |
900×H1100mm |
1100×H1200mm |
1250×H1350mm |
1400×H1600mm |
Power type |
Arc power, filament power, pulse bias power, direct current magnetic power, intermediate frequency magnetic power, sputter magnetic power, linear away source |
||||
Vacuum chamber structure |
Vertical front door structure, postposition sucking gas system, double layer water cooling chamber |
||||
Vacuum chamber material |
High quality stainless steel chamber |
||||
Ultimate vacuum |
6.0×10-4Pa |
||||
Total power |
40KW |
45KW |
50KW |
60KW |
75KW |
Occupy area |
W2m×L3m |
W2.5m×L3.5m |
W3m×L4m |
W4m×L5m |
W4.5m×L6m |
Other technical parameter |
Water voltage ≥0.2MPa, water temperature ≥0.2MPa, air pressure 0.5-0.8MPa |
||||
Remark |
Vacuum coating machine detailed configuration can be design according to customers product technological requirements. |
||||
It is applicable in decorative film in various plastic products, and glass. The aluminum-coated film is bright, delicate coating speed, high efficiency and simple operation, equipment stability.
We are able to supply customized vertical single-open and double-open or horizontal film coating machine according to the requirements of our customers.
Vacuum evaporation aluminum coating equipment main models and parameters
