Help CenterPlastic Beads Vacuum Metalization Machine
Related Products
-
Medal PVD Vacuum Metallizing MachineNegotiableMOQ: 1 Set -
CCZK-900 Vertical Shoe Heel Vacuum Evaporation Coating MachineNegotiableMOQ: 1 Set
-
Perfume Caps Vacuum Metallizing MachineUS$ 20,000 - 100,000MOQ: 1 Set
-
Resin Diamond Vacuum Metalizing MachineNegotiableMOQ: 1 Set
-
High Vacuum Metalizing Machine for Perfume CapsNegotiableMOQ: 1 Set
Specifications
1.Certified ISO90012.Nice after-sales service
3.Strong technology support
4.Size customized
5.Warranty: 1 year
1.Features: Aluminum Film Vacuum Coating Machine adopts the resistance heating in the vacuum chamber, to melt and vaporize the metal wire (aluminum wire) cling to the resistance wire. The vaporized metal molecule deposit on the substrates, to gain the smooth film as well as high reflectivity. Thus the surface of the items can be decorated and beautified. With a reasonable structure, coating evenly into good quality, pumping speed, the cycle of short, high efficiency and easy operation, low energy consumption and performance advantages of stability.
2.Application:Widely used in reflective Cup, cosmetics, shoe heel, TPU, ABS, PS, PP, PC, PVC, PET, nylon, metal, Boli, glass, ceramics, audio and various small appliances, sanitary,clocks and watches, cell phones,cosmetic caps, cosmetics,toys,etc.
3.We can design machine based on user requirements specification models of Vacuum Coaters. Vacuum units and electric control system can be designed according to user requirements.
Technical Parameters:
1> Vacuum chamber: ø900mm×1000mm
2>Vacuum degree: (ultimate vacuum) 8×10 -4 Pa(clean vessel, idle load)
3.>Pumping speed: 5×10-2≤5min (clean vessel, idle load)
4>Evaporation power:380V/12V 20KW
5>Total power: 380V 50Hz 20KW (max. 30KW within short time)
6>Total water volume: 0.2Mpa 3m3/h
7>Total gas volume: 0.4-0.8Mpa
