Specifications
1.Certified ISO90012.Nice after-sales service
3.Strong technology support
4.Size can be customized
5.Warranty: 1year
1. Plastic cap golden color machine :Main characteristic of equipment
It is easy and quick to clamp the parts and it’s simple for the operator to keep in convenient for repairing in case it needs .The work rest adopts the revolution and rotation structure of gear-driven, driving agilely and safely. The equipment of the vacuum set is modern and reasonable, whose speed is fast and efficiency is high. Equipment components almost adopt the imported parts or high quality product from jointly venture companies in China.
2.PVD vacuum coating machine Main structure of equipment
2.1 Each door is equipped with one set of work rest and one set of vaporization electrode ( ie, two sets of vap orization electrode.)
2.2 Control mode: manual control and automatic control.
2.3 The core of the diffusion pump is made of carbon steel, the copper housing of the diffusion pump is cooled through two-stage.
2.4 The vaporization electrode uses the red copper stick which is Φ30mm.
3. Glass bottle coloring machine Main specifications:
3.1 Size of vacuum chamber:1000mm* H1000mm;
3.2 Ultimate pressure: 8.0x 10-4pa
3.2 Ultimate pressure: 8.0x 10-4pa
3.3 Working pressure : 5´10-²pa≤15mins
3.5 Power: 3 phase, 4lines,380 V±10% 50HZ Total power≈ 35KW;
3.6 Colling water: pressure≥0.2MPa,temeperature≤20°C,water consumption≈15T/h;
3.7 Compressed air required: 0.5Mpa—0.8Mpa;
3.8 Occupy space: W3m´W3m
